MODE DESCRIPTION PARAMETERS
Analog (continued)
27 0 or 4 mA Trim ________________________
28 20 mA Trim ________________________
Volume
29 Tank Type ________________________
30 Mult Above ________________________
31 Mult Below ________________________
32 Span ________________________
33 Tank Length ________________________
34 Sphere. Length ________________________
35 Tank Radius ________________________
Differential
36 Change Senor # ________________________
37 Display Control ________________________
Open Channel Flow
38 Constant Above ________________________
39 Constant Below ________________________
40 Decimal Point ________________________
41 Tank Span ________________________
42 Exponent Above ________________________
43 Exponent Below ________________________
Calibration
44 Temp Comp ________________________
45 Distance Offset ________________________
46 Offset Polarity ________________________
47 Calibration Above ________________________
48 Calibration Below ________________________
Utilities
49 Reset ________________________
50 Software Version ________________________
