Warning CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN WARNING: TO REDUCE THE RISK OF ELECTRIC SHOCK DO NOT REMOVE COVER (OR BACK). NO USER SERVICEABLE PARTS INSIDE. REFER TO QUALIFIED PERSONNEL. The lighting flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of uninsulated “dangerous voltage” within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons.
Thank you for purchasing the Apex Digital AVL2076 20” LCD Television. This LCD TV is designed to be versatile, ergonomic, and easy-to-use. It has a wide variety of inputs for connecting to most any video device you already own. Please take a moment and inspect the contents of your LCD display.
Functions Remote Control - All functions can be controlled using the remote control. - Some functions can also be adjusted with the buttons on the top panel of the set 1. POWER Turns the LCD display on or off. 2 2. MTS Cycles through available sound options on certain television programming. 3. MUTE Press once to turn off the sound of the LCD TV. Press again, or press volume +/ , to restore the sound. 4. ADD (FAV CH) Allows for programming of favorite channels.
TV Mode Menu Adjustments Menu adjustments are available to change the settings of your LCD TV to your preferences. Over the next few pages you will be shown how to adjust all available input sources. Press the MAIN button on the remote until TV mode is displayed. Use / buttons on the ‘diamond’ to select each sub menu. Once you’ve selected your desired menu, you may then use the / buttons on the ‘diamond’ to adjust the settings.
AUDIO 44 VOLUME BRIGHTNESS 35 CO LOR 26 HUE 26 SHARPNESS 4 MISCELLANEOUS 7 OSD TIMER 30 SEC BASS 12 LANGUAGE ENGLISH TREBLE 12 PIP SIZE 4 PIP POSITION 3 RESET RESET RESET Highlight Contrast to Increase or decrease the picture contrast. Highlight Volume to adjust the vol ume to the level you want. Highlight Brightness to make picture brighter or darker. Highlight decrease Highlight Color to increase decrease the saturation of color.
Component (YPbPr) Mode Menu Adjustments Press the MAIN button on the remote until COMPONENT (YPbPr) mode is displayed. Use / buttons on the ‘diamond’ to select each sub menu. Once you’ve selected your desired menu, you may then use the / buttons on the ‘diamond’ to adjust the settings.
D I S P L AY GEOM ETRIC MISCELLANEOUS AUDI O CONTRAST 34 CLOCK 1 V O L UM E 7 OSD TIMER 30 SEC BRIGHTNESS 49 PHASE 1 BAS S 12 LANGUAGE ENGLISH H POSITION 1 T RE BL E 12 PIP SIZE 3 V POSITION 1 PIP POSITION 4 COLOR TEMP USER RED 128 GREEN 128 BLUE 128 RESET RESET RE S E T WHITE BALANCE R E S E T Highlight Auto (Automatic adjust ment) for television circuitry to auto matically adjust the picture.
TV Menu Press the TV button on the remote then MENU button. Then press button once. Use / button to select each sub menu. Once you’ve selected your desired menu, you may then use the / buttons to adjust the setting. Descriptions TV Rating CCD Use this to activate the subtitle and teletext function. Each sequential press of the CCD button will show: CCI-CC4, T1-T4, OFF. CH Scan (automatic channel scanning) To activate CH Scan, press button to execute the automatic channel scanning.
Troubleshooting 17 We encourage you to visit our website at www.apexdigitalinc.com and review the Customer Support and FAQ’s page for updates to this list. You should register to validate your warranty at this website. You can also order accessories for all of your Apex products. Problems No picture Abnormal or no colors Solutions Connect power cord correctly. Turn on power via the button on LCD TV. (p. 7) Check your video connections. (p.
Q: Why is the power LED on but the screen is blank? A: Make sure the video cable is securely connected to both the LCD TV and the device you have attached. Also, make sure you have correctly connected all of the cables required for your device. Refer to the user’s manual that came with your equipment for further information.
Specifications 19 Pixel Pitch 0.6375 mm (H) x 0.6375 mm (W) Maximum Display Area 16.1 in. (V) x 12.1 in. (H) (408 mm x 306 mm) 20.1 in. diagonally Aspect Ratio 4:3 Native Resolution 640x480 interlaced or progressive Display Colors 16.
Apex Digital AVL2076 Apex Digital, Inc. expresses the following limited warranty. This warranty extends to the original consumer, purchaser or product received as a gift and no other purchaser or trans feree. You must retain the original bill of sale for proof of purchase.
