How to Replace Stage-2 Carbon Filter (CT-24CAB)
Change every 6 months or 600-800 gal pure water used:
Figure E
(Back View Of System)
The Stage-2 Pre-Carbon filter is located between Stage-1 and Stage-4 filters (See Figure E). Locate it, and
follow these steps:
Step 1.
Step 2.
Disconnect tubing from Point F & Point G (See Figure E). Discard used Filter.
(Follow “Quick-Connection Guide” for connection tips)
Snap on the new filter onto the 2 holding clips. Make sure the Flow Direction “ Arrow” on the
filter is pointing towards the left direction (See Figure E). Reconnect tubing to both ends of the
new filter.
