User Manual

3Smart-UPS On-Line SRT Transformer
Product Description
The Smart-UPS™ RT transformer is designed for use as an isolation transformer. Models SURT003 and SURT004
also function as a step down transformer.
The tower unit can be placed in a standard 19-inch rack. It should be mounted in the rack above the UPS using a
specialized APC by Schneider Electric rail kit. The rail kit, SURTRK2, is sold separately as an accessory. See the
APC by Schneider Electric website www.apc.com or contact your APC by Schneider Electric sales representative
for additional information.
The UPS and transformer models may vary from the examples depicted in this manual.
Product Overview
Specifications
For additional specifications refer to the APC by Schneider Electric web site, www.apc.com.
Electrical
SURT001 SURT002 SURT003 SURT004
Nominal Input Voltage (Vac) 220–240 208 or 220-240 200 or 220
Input Voltage Range (Vac) 170–280
Input Service Maximum Current (Amps) 16 30
Input Connection IEC C20 Hardwire
(10 AWG)
3 ft. cord with L6-30P
Line Frequency (Hz) 45–65
Nominal Output Voltage (Vac) 220–240 220-240/208/
110/120
200/100 or
220/110
Output Receptacles IEC C19 Hardwire
(10 AWG)
(2) L6-20R
(1) L6-30R
(1) L14-30R
(8) 5-20R
T-slot
(1) L6-20R
(1) L6-30R
(2) L5-20R
(8) 5-20R
T-slot
Maximum Output Power (VA) 3000 5000 4800 4600
Maximum Output Power (Watt) 3000 5000 4800 4600
