User manual
Table Of Contents
- Introduction
- Overview
- Unpack package contents
- Read the Safety Guide before installing the UPS.
- Hardware supplied
- Accessories
- Install accessories prior to connecting power to the UPS.
- Optional accessories
- Specifications
- Environmental Specifications
- Physical Specifications
- Front and rear panels
- Installation
- Output hardwire instructions
- Input hardwire instructions
- Connect the internal battery charger
- Tower configuration
- Install stabilizer brackets
- Install display panel
- Install bezel
- 2-post rack-mount configuration
- Remove and rotate display panel
- Position UPS for mounting in rack
- Install rack-mount brackets
- Secure 2-post rack to floor
- Install UPS in rack
- Install display panel
- Install bezel
- Start-up
- Connect equipment and external battery packs to UPS
- Prior to connecting the grounding cable, ensure that the UPS is NOT connected to utility or battery power.
- Start the UPS
- Operation
- Front panel display
- Display panel function buttons and indicators
- UPS function buttons
- UPS indicators
- Configuration
- UPS Settings
- Settings are adjusted through PowerChute software or optional SmartSlot accessory cards.
- Emergency Power Off (EPO)
- Connect the EPO
- External batteries
- APC battery solution
- Third party battery solution
- Connect the UPS to a battery system
- Configure UPS parameters
- Troubleshooting
- Transporting the UPS
- Prepare the UPS for transport
- Regulatory Agency Approvals and Radio Frequency Warnings
- Class A
- Service
- Contact Information
- Two-Year Warranty

User Manual Smart-UPS RC UXI/UXICH 1000/2000/3000 VA 220/230/240 Vac Tower/Rack-Mount 4U 14
Output voltage Allows user to select output voltage while on-line.
220 V models 220 Vac 200, 208, 220,
230, 240 Vac
230 V models 230 Vac 200, 208, 220,
230, 240 Vac
Output frequency Automatic
50 ± 3 Hz
60 ± 3 Hz
Automatic
50 ± 3 Hz, 50 ± 0.1 Hz,
60 ± 3 Hz, 60 ± 0.1 Hz
Sets allowable UPS output frequency. Whenever
possible, output frequency tracks input frequency.
Number of
battery strings
1 Number of connected
battery strings
Defines number of connected battery strings for
proper run time prediction.
1000/2000 VA models default setting of 1=432 VAh, 96 V x 4.5 Ah
Refer to XLBP user manual for details on
configuring UPS and # of battery strings.
3000 VA models default setting of 1=691 VAh, 96 V x 7.2 Ah
Refer to XLBP user manual for details on
configuring UPS and # of battery strings.
Configuration for a third party battery solution
Examples: 1 battery string = 691 VAh, 96 V x 7.2 Ah; 2 battery strings = 1382 VAh, 96 V x 14.4 Ah
Function Factory Default User Selectable
Choices
Description
