User Manual Smart-UPS RC UXI/UXICH 1000/2000/3000 VA 220/230/240 Vac Tower/Rack-Mount 4U 10
Start-up
Connect equipment and external battery packs to UPS
Prior to connecting the grounding cable, ensure that the UPS is NOT connected to
utility or battery power.
1. Connect equipment to UPS (cables not supplied). Avoid using extension cords.
2. External battery packs provide extended runtime during power outages. This unit supports up to ten
external battery packs. Refer to the APC Web site, www.apc.com for information. Refer to the user manual
for the external battery pack for installation instructions.
3. Switch the circuit breaker ON.
4. To use UPS as a master on/off switch be sure all connected equipment is switched on. Equipment will not
receive power until UPS is turned on.
5. Configure Network Management card (NMC). Refer to NMC documentation for instructions.
Start the UPS
The charge time for external batteries will vary depending on the number of batteries connected to the
UPS. Refer to the APC Web site, www.apc.com for APC battery runtimes.
Press the TEST button located on the front panel of UPS.
