Configuration: Settings
990-3054B-001 Modular Power Distribution Unit – Operation 13
How to set the alarm thresholds for all Power Distribution Modules in the system
The Mass Configuration screens are used to set the alarm thresholds for all Power Distribution Modules
in the system.
Select Circuit Cfg on the
Main Menu Screen, and
press
ENTER.
Select Mass
Configuration and press
ENTER.
Change the settings for
Threshold Values:
Select the maximum
and minimum values
that should generate
an alarm.
Threshold Enable:
Enable or disable the
alarms for the
different settings.
Breaker Position:
Enable or disable
alarms when a breaker
is opened.
Select Apply to All and press ENTER to confirm your changes.
>Individual Load Cfg
>Mass Configuration
>Reset Ckt Defaults
>Breaker Position
Alarms:>Enabled
>Alarms:>
OFF
>Min:>ON High:>OFF
>Low:>
OFF >Max: >OFF
>Apply to All
Pick Alarm Limits:
>Min:>xx% >Hi: >xx%
>Low:>xx% >Max:>xx%
>Threshold Values
Mass Configuration:
>Threshold Enable
>Breaker Position
>Apply to All
>Apply to All
Module View Alarms
Load/Energy
Circuit Cfg Admin
Volt Meter
Log
Help
>Electrical Config
