Configuration: Settings
12 Modular Power Distribution Unit – Operation 990-3054B-001
How to set the individual alarm thresholds
The Individual Load Cfg screens are used to set the alarm thresholds for a single Power Distribution
Module in the system.
It is also possible to set the settings for all modules at the same time. Refer to "How to set the
alarm thresholds for all Power Distribution Modules in the system".
Select Circuit Cfg on the Main Menu Screen, and
press
ENTER.
Select Individual Load Cfg and press ENTER.
Scroll through the modules/circuits to go to the
desired module/circuit. Press
ENTER to select a
specific module/circuit.
Change the settings for:
Alarms: Select to enable or disable alarms.
Alarm Thresholds: Select to change the
settings for Warning Thresholds, Critical
Thresholds, and Position Alarms.
Reset to defaults: Select to reset to factory
defaults.
>Individual Load Cfg
>Mass Configuration
>Reset Ckt Defaults
<Circuit Name>
Mod:>xx Cable:>yy
>Name/Location
>Alarm Configuration
>Alarms:>Enabled
Mod xx, Cable yy:
>Alarm Thresholds
>Reset to defaults
Module View Alarms
Load/Energy
Circuit Cfg Admin
Volt Meter
Log
Help
>Electrical Config
