Configuration: Settings
990-3054B-001 Modular Power Distribution Unit – Operation 11
How to set the name and location of the circuits
Select Circuit Cfg on the Main Menu Screen, and
press
ENTER.
Select Individual Load Cfg and press ENTER.
Select Name/Location and press ENTER.
Change the settings for circuit name and circuit
location. Use the
UP and DOWN arrow keys to select a
character and press
ENTER to confirm and go to the
next character.
>Individual Load Cfg
>Mass Configuration
>Reset Ckt Defaults
<Circuit Name>
Mod:>xx Cable:>yy
>Name/Location
>Alarm Configuration
»circuit name
Mxx, Cable y:
>Location
»circuit location
Module View Alarms
Load/Energy
Circuit Cfg Admin
Volt Meter
Log
Help
>Electrical Config
