10 Modular Power Distribution Unit – Operation 990-3054B-001
Configuration
Settings
How to set up the network
Select Admin on the Main Menu Screen, and press
ENTER.
Select Network Setup and press ENTER.
Set the IP-address and subnet mask for the system.
Press the continue arrow and set the gateway and
MAC address.
>Mode: Fixed IP Addr
<Network Status>
IP:xxx.xxx.xxx.xxx
Module View Alarms
Load/Energy
Circuit Cfg Admin
Volt Meter
Log
Help
>Network Setup
>Local Interface
>Date & Time
>Device ID
SM:xxx.xxx.xxx.xxx
MAC Address:
GW:
xxx.xxx.xxx.xxx
xx xx xx xx xx xx
