Operation: Operation Procedures
8 Modular Power Distribution Unit – Operation 990-3054B-001
How to view circuit status information
The Load/Energy screens are used for status information on a circuit level and the data is grouped by
output cable. Scroll to the list to go to the specific circuit. The circuit names are stated for identification.
Refer to "How to set the name and location of the circuits" for information on how to set the
circuit name.

Select Load/Energy on
the Main Menu Screen
and press
ENTER.

Select to view either
 Current & Power
 Percent Loading
 Energy Usage. Press
ENTER at the Reset
prompt and confirm
the reset to zero the
kWh registration for
the circuit and set the
reset date to the current
date.
How to view output voltages

Select Vo l t Meter on the
Main Menu Screen and
press
ENTER.

The Output Voltage
Screen shows the output
voltages for the three
phases and the phase-to-
phase voltages
.
Circuit Loading
>Current & Power
>Percent Loading
>Energy Usage
Mod:>xx Cable:>yy
<Circuit Name>:
L1:xxA L2:xxA L3:xxA
Mod xx, Cable:>yy
L1:xx.xA xxx%
L2:xx.xA xxx%
L3:xx.xA xxx%
Mod:>xx Cable:>yy
<Circuit Name>
Energy: xxx,xxx kWh





Total Power: xx.xkW
>Reset: mm/dd/yyyy
Module View Alarms
Load/Energy
Circuit Cfg Admin
Volt Meter
Log
Help
Output Voltage
L1: xxx L1-2: xxx
L2: xxx L2-3: xxx
L3: xxx L3-1: xxx


Module View Alarms
Load/Energy
Circuit Cfg Admin
Volt Meter
Log
Help
