Operation: Operation Procedures
990-3054B-001 Modular Power Distribution Unit – Operation 7
How to view Power Distribution Module information
Select Module View on
the Main Menu Screen
and press
ENTER.
Press ENTER at the
Module number and
scroll through the list of
modules to the specific
module and press
ENTER.
Select About This
Module and press
ENTER.
Select to view either:
Module Mfg Info
Cable Details
Breaker Ratings
Module:>xx
>Module Mfg Info
>Cable Details
>Breaker Ratings
Module xx Info>:
Model: zz
Mod xx, Cable:>yy
Length: 3.0m (9.8ft)
Connector: IEC309-3W
Voltages 230V
Mod xx, Cable:>yy
Breaker Ratings:
L1:20A L2:20A L3:20A
Module View Alarms
Load/Energy
Circuit Cfg Admin
Volt Meter
Log
Help
Module:>xx
Status: Critical
>Circuit Details
>About This Module
S/N: xxxxxxxxxxxx
Mfg Date: dd/mm/yyyy
