Operation: Operation Procedures
6 Modular Power Distribution Unit – Operation 990-3054B-001
How to view the Power Distribution Module status
The Module View Screens are used for status information on a Power Distribution Module level.
Select Module View
on the Main Menu
Screen and press
ENTER.
Press ENTER at the
Module number and
scroll through the list
of modules to the
specific module and
press
ENTER.
To view more
information about the
module, select Circuit
Details and press
ENTER.
In 3-corded systems,
select the relevant
cable and press
ENTER.
Scroll through the
three status screens for
information on the
specific Power
Distribution Module.
The example shows
that there is a warning alarm on L2.
Module:>xx
Status: Critical
>Circuit Details
>About This Module
Module xx: y Cables
>Cable 1: Normal
>Cable 2: Critical
>Cable 3: Normal
Module xx, Cable y:
Name:
<Circuit Name>
Power: xx.x kW
Mod xx, Breakers:
L1: Closed
L2: Open
L3: Closed
Mod xx, Cable y:
L1: 10.1A 051%
L2: 11.4A 057% High!
L3: 04.4A 025%
One-corded
Three-corded
Module View Alarms
Load/Energy
Circuit Cfg Admin
Volt Meter
Log
Help
