3.3.2 STS Measurements
Click on the “Measurements” section in the menu.
The following measurements are saved and time-stamped:
◗ “Source 1 voltage”: Value of the utility voltage supplying your STS (value of the first phase)
◗ “Source 1 frequency”: Value of the utility frequency feeding your STS
◗ “Source 2 voltage”: Value of the utility voltage supplying your STS (value of the first phase)
◗ “Source 2 frequency”: Value of the utility frequency feeding your STS
◗ “Output voltage”: Value of the output voltage of your STS (value of the first phase)
◗ “Output load”: Value of the percentage of load at STS output (value of loaded for the 3-phase)
◗ “ Output current Ph x”: Value of the output current for each phase on three-phase STSs
◗ The save frequency of these values is defined in the “System” page (60 seconds by default).
Approximately 1000 time-stamps are stored permanently on the card. The oldest time-stamps are
automatically deleted.
◗ “Save” enables all saved values to be opened or saved in CSV format (compatible with Excel type
spreadsheets)
“Clear” enables deletion of all records. The administrator must enter his login / password to validate this
action if he has not already done so during the current session.
