2.5.3 Mounting Options
The DC MX06 60A Shelf has 3 positions for mounting ears. If mounting ears were ordered with the
system they will be fitted in the front position as standard. The 2 alternative mounting positions are
shown below. The end user can simply unscrew the ears and re-fit in the desired position.
Ensure all screws are re-tightened sufficiently.
Mountin
g
Ears
Optional Mounting
Positions
