Information

Revision 1, April 2014
Product feature SMC1000I-2U SMC1500I-2U
Output
Power Capacity 600W/1000VA 900W/1500VA
Nominal Output Voltage 230V
Output Frequency 47-63Hz
Wave Form Type Sine wave
Output Connections (4) IEC 320 C13
Input
Nominal Input Voltage 230V
Input Voltage Range for main
operations (Max adjustable range)
180-287V (170-300V)
Input Frequency 50/60 Hz +/-3 Hz (auto sensing)
Input Connection IEC 320 C14
Batteries and Runtime
Battery Type Maintenance-free sealed lead-acid battery with suspended electrolyte, leak proof
Typical Backup Time at 1/2 Load
(min)
14 min 18 min
Typical Backup Time at full Load
(min) 5 min 6 min
Replacement Battery APCRBC124 APCRBC132
Communication and Management
Interface Ports USB, Serial (RJ45)
Control Panel and audible alarms Etched glass LCD display with LED status indicators; alarm on battery, distinctive low battery alarm
Surge Protection and Filtering
Surge Energy Rating 455J 455 J
Filtering
Full time multi-pole noise filtering: 0.3% IEEE surge let-through, zero clamping response time, meets
UL1449
Physical
Maximum Height (in) 89 mm (3.5 in) 89 mm (3.5 in)
Maximum Width (in) 432 mm (17.0 in) 432 mm (17.0 in)
Maximum Depth (in) 406 mm (16.0 in) 475 mm (18.7 in)
Net Weight 20.52 kg (45.15 lbs) 27.82 kg (61.2 lbs)
Conformance
Regulatory VDE, CE, GOST, C-Tick
Warranty and Equipment Protection
Policy
2 years repair or replace
Rackmount models
