Information

Revision 1, April 2014
Product feature SMC2000I SMC3000I
Output
Power Capacity 1300W/2000VA 2100W/3000VA
Nominal Output Voltage 230V
Output Frequency 47-63Hz
Wave Form Type Sine wave
Output Connections (6) IEC 320 C13, (1) C19 (8) IEC 320 C13, (1) C19
Input
Nominal Input Voltage 230V
Input Voltage Range for main
operations (Max adjustable range)
180-287V (170-300V)
Input Frequency 50/60 Hz +/-3 Hz (auto sensing)
Input Connection IEC 320 C14
Batteries and Runtime
Battery Type Maintenance-free sealed lead-acid battery with suspended electrolyte, leak proof
Typical Backup Time at 1/2 Load
(min)
17 min 11 min
Typical Backup Time at full Load
(min) 6.5 Min 3.5 min
Replacement Battery APCRBC148 APCRBC150
Communication and Management
Interface Ports USB and Serial (RJ45)
Control Panel and audible alarms Etched glass LCD display with LED status indicators; alarm on battery, distinctive low battery alarm
Surge Protection and Filtering
Surge Energy Rating 730 J 724 J
Filtering Full time multi-pole noise filtering: 0.3% IEEE surge let-through, zero clamping response time
Physical
Maximum Height 216 mm (8.50 in) 435 mm (17.13 in)
Maximum Width 170 mm (6.69 in) 197 mm (7.76 in)
Maximum Depth 440 mm (17.32 in) 544 mm (21.42 in)
Net Weight 27.50 kg (61 lbs) 43 kg (95 lbs)
Conformance
Regulatory VDE-GS, CE, EAC, C-Tick, IRAM, SABS
Warranty and Equipment Protection
Policy
2 years repair or replace
Tower models
