Information

Revision 1, April 2014
Product feature SMC1000I SMC1500I
Output
Power Capacity 600W/1000VA 900W/1500VA
Nominal Output Voltage 230V
Output Frequency 47-63Hz
Wave Form Type Sine wave
Output Connections (8) IEC 320 C13
Input
Nominal Input Voltage 230V
Input Voltage Range for main
operations (Max adjustable range)
180-287V (170-300V)
Input Frequency 50/60 Hz +/-3 Hz (auto sensing)
Input Connection IEC 320 C14
Batteries and Runtime
Battery Type Maintenance-free sealed lead-acid battery with suspended electrolyte, leak proof
Typical Backup Time at 1/2 Load
(min)
14 min 11 min
Typical Backup Time at full Load
(min) 5.Min 4 min
Replacement Battery APCRBC142 RBC6
Communication and Management
Interface Ports USB and Serial (RJ45)
Control Panel and audible alarms Etched glass LCD display with LED status indicators; alarm on battery, distinctive low battery alarm
Surge Protection and Filtering
Surge Energy Rating 455J
Filtering Full time multi-pole noise filtering: 0.3% IEEE surge let-through, zero clamping response time
Physical
Maximum Height 215 mm (8.62 in) 215 mm (8.62 in)
Maximum Width 171 mm (6.73 in) 171 mm (6.73 in)
Maximum Depth 439 mm (17.28 in) 439 mm (17.28 in)
Net Weight 17.27 kg (38 lbs) 20.45 kg (45 lbs)
Conformance
Regulatory VDE, CE, GOST, C-Tick
Warranty and Equipment Protection
Policy
2 years repair or replace
Tower models
