Specifications

InstructionsetPM1122‐INT

ThePM1122‐INTcanbecontrolledusingRS‐232.Initialportsettingsare19200bitspersecond,8data
bits,noparity,1stopbitandnoflowcontrol.Thebaudratecanbeconfiguredatdifferentvalues,but
thiswillbedescribedlater.FordetailsontheserialcableandTerminalconnectionsettings,refertothe
PM1122‐INTinterfaceserialcommunicationsetupdocument.

StandardASCIIstringsareusedtocontrolthePM1122‐INTsoit’spossibletouseTerminalsoftware(e.g.
HyperTerminal)totest,configureand/orcontrolit.Instructionsarenotcasesensitive.Eachstringmust
beendedwithaCarriageReturn(ASCIIcode13or\n)

Aninstructionconsistsofacommand,anattributeandpossibleoneoremoreparameters.E.g.the
instructiontoswitchthemusic volumefromzone1atmaximumwilllooklikethis:
SETMSCLVLZONE1100\n
whereSETistheinstruction,MSCLVLtheattribute,ZONE1thefirstparameterand100thesecond
parameter.

Commands

Thisisalistofcommandswithabriefdescription

SET Setthevalueofavariable
GET Getthevalueofavariable
RCL RecallaPreset
LRN LearnacodeofEasywaveRFswitch
CLR ClearpresetorEasywaveRFcodes
HELP ListsCommandsandAttributes
LST ListsCommandsandAttributes (sameasHELP)
STR StoreaPreset
INC Increasethevalueofavariable
DEC Decreasethevalueofavariable

Attributes


Theattributescanbegroupedincontrolsandsettings.Controlswillreally“control”thePM1122while
settingsonlydeterminethebehaviourofthePM1122‐INT.
