Specifications



PM1122‐INTDigitalInterfaceRemoteserialcommunicationsetup.

InordertocommunicatewiththePM1122remoteinterfaceusingapersonalcomputer,youwill
havetosetupyourcommunicationparameterscorrectly.Youalsoneed sufficientrightsonyour
computer,soaskyoursystemadministratorforassistanceifnecessary.Serialcable
specificationsarealsomentionedbelow.
OnaPCrunningonWindows2000/XP,youwillfindasuitablecommunicationprogramcalled
Hyperterminal(Start‐>Allprograms‐>Accessories‐>Communications‐>Hyperterminal).
Opentheprogram.Ifapopupscreencomesupaskingyoutomakeityourdefaulttelnet
program,clickcancel.Nextyoumaybeaskedwhattelephonelineyouwillbeusing,ignorethis
andselectyourPCserialcommunicationportasstandard,usuallythisisCOM1.Pleasetakea
lookatthescreenshotsbelowforclarification.ForthosewhoarefamiliarwithHyperterminal,
defaultcomsettingsonthePM1122‐INTare“19200:8:none:1”
Open“Hyperterminal”.
MakeanewconnectionandcallitPM1122.Underthepull‐downmenulabeled“File”,click
“NewConnection”tocreateanewconnection.







