System Basis Chips (SBCs)
www.infineon.com/sbc
The Driver SBCs Family
The driver SBC is the first family of the new generation of
Infineon SBC in an exposed pad PG-VQFN-48 (7mm x
7mm) power package. The family oers several variants
to meet the dierent application requirements. The
devices are designed for various CAN-LIN automotive body
applications as a main supply for the microcontroller
and as an interface for a CAN and LIN bus network (optional
CAN partial networking). To support these applications,
the Driver SBC provides the main functions, such as a 5V
low-dropout voltage regulator (LDO) for microcontroller
supply, a 5V low-dropout voltage regulator with short
circuit protection against supply voltage V
S
for e.g. sensor
supply, HS-CAN transceiver and LIN transceiver for data
transmission, fully protected Low- and High-Side Switches,
and a 16-bit Serial Peripheral Interface (SPI) to control
and monitor the device. Also implemented are a Window
Watchdog circuit with a reset feature, a fail output and
an under voltage reset feature. The device oers low-power
modes in order to support applications that are connected
permanently to the battery. A wake up from the low-power
mode is possible via a message on the buses, via the
bi-level sensitive monitoring/wake-up inputs as well as via
cyclic wake. The device is designed to withstand the
severe conditions of automotive applications.
Features
Low-drop voltage regulator 5V, 250mA
Low-drop voltage regulator 5V, 100mA, robust
against short to V
S
High-speed CAN transceiver ISO 11898-2/5
LIN transceiver LIN 2.2, J2602-2
Fully compliant to “Hardware Requirements for LIN,
CAN and FlexRay Interfaces in Automotive Applications”
Revision 1.3, 2012-05-04
Two low-side outputs and six high-side outputs
Four wake inputs, reset output and fail output
Overtemperature and short circuit
protection feature
Applications
Door control units
Central body computer
Low cost bodycontrol
HVAC control module
Trunk control module
Seat control
Roof module
