www.infineon.com/embeddedpower
Infineon has combined its wealth of experience in
motor control drivers for automotive applications with
an industry-standard core. The unique result, our 3
rd
generation embedded power IC based on ARM® Cortex®-M
cores, addresses a wide range of smart 2-phase DC motor
control applications like, sunroof, power window li,
electrical pumps, electrical fans.
Produced on Infineon’s first-in-industry automotive
qualified 130nm smart power technology, the Infineon
embedded power system-on-chip solutions oer
an unmatched level integration and system cost to
performance to optimization for the target application
segments.
The TLE986x family oers scalability in terms of flash
memory sizes and MCU system clock frequency supporting
a wide range of motor control algorithms. It uses the same
MCU and peripherals as the TLE987x family, 3-phase driver,
enabling design synergies between DC and BLDC motor
control applications
TLE986x Family Oers
 Four current programmable drivers with charge pump for
N-Channel MOSFET
 Integrated LIN transceiver compatible with LIN 2.2 and
SAEJ2602
 Two full duplex serial interface (UART) with LIN support
 Two Synchronous Serial Channel (SSC)
 On-chip OSC and PLL for clock generation
 One high voltage monitoring input with wake up
functionality
 High speed operational amplifier for motor current
sensing via shunt
 Measurement unit:
– 8-bit ADC module with 10 multiplexed inputs
– 10-bit ADC module with 8 multiplexed inputs, 5
external analog inputs
– On chip temperature and battery voltage
measurement unit
 Independent programmable window watchdog
 5V/1.5V Internal supplies
 External supply (VDDEXT): 5V ±2% @ 20mA
 Power saving modes
– MCU slow-down mode
– Sleep mode
– Stop mode
– Cyclic wake-up sleep mode
Features of the Microcontroller
 32-bit ARM® Cortex® M3 Core, up to 40MHz clock
frequency
 36KB to 128KB flash memory
 Up to 6KB RAM memory
 Harvard architecture
 Thumb®-2 Instruction Set and hardware divide and
multiplication unit
 Four 16-bit timers
 Capture/compare unit for PWM signal generation (CCU6)
with 2x 16-bits timers
General Characteristics
 Operating supply voltage V
s
= 5.5 to 28V,
maximum rating 40V
 Extended operating range V
s
= 3.0 to 28V,
MCU / Flash fully functional
 ESD performance :
– up to 2kV / handling on all pins
– 4kV @ HV inputs
– 6kV @ LIN pin
 Overvoltage device clamp (load dump ruggedness)
up to 40V
 Wide operating temperature range:
T
j
: -40°C up to 150°C
3
rd
Generation: 2-Phase Bridge Driver IC with Integrated ARM® Cortex® M3 Core
