The 2
nd
generation of Infineon® embedded power ICs
integrates on a single die all the necessary functions to
sense, control and actuate motor a via a relay or via a PN
MOSFET half-bridge. The TLE983x product family integrates
a high performance 8-bit microcontroller derived from the
established XC800 microcontroller family with application
specific power drivers, control and communication on
Infineon’s first-in-industry automotive qualified 130nm
smart power technology. TLE983x product family improves
the microcontroller performance and the product feature
set over the first generation (TLE78xx) product oering.
The TLE983x product family is oered in a space saving
PG-VQFN-48 package, while the first product generation
is realized as a Multi-Chip-Module (MCM) in a DSO-28
package.
The devices are designed for LIN based motor control
applications such as window lis, wipers, sun roofs, power
seats, fan/blower control.
General Characteristics
 Operating voltage VBat: 3.0V to 27V, maximum rating 40V
 Stop mode 85µA & sleep mode 25µA
 ESD performance:
– up to 2kV / handling on all pins
– 4kV @ HV inputs
– 6kV @ LIN pin
– ECU/car handling ruggedness (gun model for pins
directly connected to ECU plug/socket)
 Overvoltage device clamp (load dump ruggedness): ≥ 40V
 Wide operating temperature range:
Tj:-40°C up to 150°C
Features of 8-bit Microcontroller, XC8xx
 8051 compatible, up 40MHz Frequency
 256byte RAM and 3072byte XRAM
 36KB to 64KB flash memory for code and data
 10-bit ADC (5V max.), 8 channels including battery and
supply supervision
 Five 16-bit timers
 Capture/compare unit for PWM signal generation (CCU6)
with 2 x 16-bits timers
TLE983x Product Family Oers
 LIN transceiver (single wire), compliant with
LIN Spec. 2.1, 2.0/SAE J2602 and compatible with LIN 1.3
 Two protected low-side switches (250mA)
 Up to two protected high-side switches (150mA)
 Five high-voltage inputs with wake up functionality
 Full duplex serial interface (UART) with LIN support
 Synchronous serial channel (SSC)
 Two watchdog timers
 Programmable window watchdog
 Measurement unit with 10 channels,
8-bit A/D Converter and data post processing
 Voltage regulator with undervoltage reset
 Power saving modes
– MCU slow-down mode
– Stop mode
– Sleep mode
– Cyclic wake-up and cyclic sense during stop mode and
sleep mode
Applications
 Window li
 Sun roof
 Fan control
 Seat control
 Key pad interface
 Switch panel interface
2
nd
Generation: Relay Driver IC with Integrated Microcontroller
www.infineon.com/embeddedpower
