Infineon® embedded power ICs are specifically designed
to enable mechatronic motor control solutions for a range
of motor control applications, where a small package form
factor and a minimum number of external components
are essential. Examples applications include window li,
sunroof, wiper, fuel pump, HVAC fans, engine cooling fan,
water pumps to name a few.
Produced on Infineon’s automotive qualified smart power
technologies, the Infineon embedded power System-on-
chip solutions oer an unmatched level of integration of all
functions required to sense, control and actuate a motor.
The Infineon® embedded power IC integrate on single
die the microcontroller, the non volatile memory, the
analog and mixed signal peripherals, the communication
interfaces along with the driving stages needed for either
relay, or half-bridge or full-bridge DC and BLDC motor
applications.
www.infineon.com/embeddedpower
Selection Tree for Infineon Embedded Power IC Motor Control
TLE9832QX
TLE9832-2QX
TLE9833QX
TLE9834QX
TLE9835QX
Infineon® Embedded Power IC
PN-Half Bridge
Motor Control
TLE9861QXA20
1)
TLE9867QXA20
1)
TLE9867QXA40
1)
TLE9869QXA20
1)
H-Bridge
Motor Control
TLE9871QXA20
1)
TLE9877QXA20
1)
TLE9877QXA40
1)
TLE9879QXA20
1)
TLE9879QXA40
1)
3-Phase Bridge
Motor Control
Relay
Motor Control
1) In production, samples available
Infineon® Embedded Power ICs
System on a Chip Motor Control
