www.infineon.com/driver-ic
Gate Driver ICs for External MOSFETs
The trend towards greater eiciency in automotive
applications also applies to electric motors. Applications
such as power steering, HVAC compressors and engine
cooling fans will be controlled by electronic motors in the
future. Infineon’s family of configurable, H-Bridge and
3-phase gate driver ICs can be combined with MOSFETs to
provide the power and eiciency these systems demand.
Applications

Power steering

Fan and pump control

Starter alternator

Seat belt pretentioner

VVT

Electric park brake

ECMT
Basic Features

Strong output stage
up to 1.5A

Precise OpAmp for current shut
monitoring

Operation down to 5.5V

Duty cycle adjustable
up to 100%
Diagnostic Features

Undervoltage

Short-circuit

Overtemperature

Overvoltage
To sub µC
or ASIC
5 V
5 V
CH1
CL1
C
CP1
4.7µF
C
VS
4.7µF
C
3µF
P-GND
P-GND
R
VS
10Ω
V
BAT
= 12V
CH2
CL2
C
CP2
4.7µF
R
DT
R
fb
R
fb
R
Vdh
R
S
AGND
INH ENA1 ENA2
GND TP
Microcontroller
or
Digital
ASIC
TLE7183F
CB1
C
CB1
4.7µF
CB2
U_fb
V_fb
W_fb
ERR1
ERR2
IL1
IH1
IL2
IH2
IL3
IH3
ISN
R
S
Shunt
ISP
SL3
GL3
SH3
GH3
SL2
GL2
SH2
GH2
SL1
GL1
SH1
GH1
DT
ADC
GND
C
CB2
4.7µF
V
O
V
RI
V
S
V
DH
V
RO
V
THOC
