www.infineon.com/novalithic
NovalithIC™ – Integrated Half Bridge
Basic Features

Low quiescent current

Capable for high PWM frequency

Logic level input

Adjustable slew rate

Cross current protection
Diagnostic Features

Overtemperature

Undervoltage

Overcurrent

Current sense and status
Protection Features

Overtemperature shutdown

Undervoltage

Overcurrent
OC = Overcurrent
CS = Current Sense
UV = Undervoltage
OT = Overtemperature
1) See packages on page 112
2) HS switch only
M
BTN89x2
V
S
V
S
GND
OUT
GND
OUT
SR
IS
IN
INH
SR
IS
IN
INH
I/OI/O I/OI/O I/O
i.e. XC866
Reset
I/O
I
V
DD
V
SS
TLE4278
TLE4678
TLE4291
WO
I/O WI
RO
Q
D
GND
IPDx0P03PxL
Microcontroller Voltage Regulator
Reverse Polarity
Protection
BTN89x2
V
S
Application Example NovalithIC™
Product Type Operating
Range [V]
R
DS(on)
path (typ)
[mΩ]
I
D(lim)
[A]
I
q
(typ)
[µA]
Switch time
(typ) [µs]
Diagnosis Protect Package
1)
BTN8962TA 5.5 ... 40 14.2 42 7 0.25 OT, OC, CS UV, OT, OC

39
BTN8982TA 5.5 ... 40 10.0 70 7 0.25 OT, OC, CS UV, OT, OC

39
NovalithIC™ Product Overview
Integrated High-Current Motor Drivers
