www.infineon.com/led-driver
Infineon® Auto LED Driver are an enabler of protected and
high performing lighting applications in automotive.
In particular the constant current regulation secures the
stable brightness of the LED over the whole automotive
temperature and voltage range.
Applications
The Infineon automotive optimized LED Drivers address
interior and exterior, low to high power automotive
LED applications such as: high and low beam, fog, DRL,
position, tail, stop, CHMSL, RCL, reverse, turn indicator,
dome, ambient lighting, status lamps etc.
Infineon® Auto LED Driver
Infineon® Auto LED drivers are divided in four sub-families
Features

Constant output current, therefore constant
brightness and extended LED lifetime

Wide input voltage range

Low drop voltage

Open-load detection

Overtemperature protection

Short-circuit proof

Reverse polarity proof

Wide temperature range

Very small SMD packages

Automotive qualified
Infineon® Basic LED Driver

Flexible linear current source family
with scalable feature set
Infineon® Linear LED Driver

BCR400 series is the most cost eective
solution to drive low power LED

Linear Current Sources for Low to
Medium Power Applications
Infineon® Power LED Driver

DC/DC converter & controller
for high power applications
The driver as well as the LED are protected gainst overstress
e.g. caused by voltage spikes or overtemperature.
Any kind of load conditions are detected by its diagnostic
features such as open load or shorted LED.
All features are required to drive LEDs in harsh automotive
environment conditions.
