SPOC™: SPI Power Controller
SPOC™ devices are high-side smart power Multichannel
switches providing embedded protection diagnosis and
intelligence. They are specially designed for standard
exterior lighting in automotive applications, but can be
used for further automotive and industrial applications
such as heating, motor driving or power distribution.
Integration helps reducing the complexity of the
lectronics, allowing board space reduction and
decreasing the need for external components. Control,
configuration and diagnosis are carried out via a Serial
Peripheral Interface (SPI), which saves I/Os on the
microcontroller and provides flexibility for the solution.
Furthermore, Fail Safe modes are supported, which
enhances safety in operation.
Re-use and design flexibility is supported through the pin,
function and package compatibility of the devices within
each SPOC™ family.
SPOC™ provides decisive advantages on system level and
for a wide range of applications.
www.infineon.com/spoc
Basic Features

Serial Peripheral Interface (SPI) (daisy-chain capable) for
control and diagnosis

CMOS-compatible parallel input pins provide
straightforward PWM operation and FailSafe

Very low stand-by current

Optimized electromagnetic compatibility

Suitable for bulbs as well as LEDs
Diagnosis Functions

Multiplexed proportional load current sense signals

High accuracy of current sense signal at wide load
current range

Latching feedback on overtemperature and
overload via SPI

Diagnosis PWM with small duty cycle possible

LED mode

Fail-safe activation via LHI pin and configuration via
input pins
Protective Functions

Reverse battery protection

Short-circuit and overload protection

Multistep current or tripping (SPOC™ FL)

Thermal shutdown with latch

Overvoltage protection

Reverse polarity protection (SPOC™ FL)

Loss of ground protection
Options

LED mode (SPOC™+, SPOC™ FL): Load type configuration
between bulbs and LEDs for products featuring the LED
mode option (current sense ratio configurable, very fast
diagnosis in LED mode)

PWM engine (SPOC™ FL): autonomous PWM generator to
reduce micro controller loading

External drive capability (SPOC™+, SPOC™ FL): ability to
control one or two smart power drivers to reduce the I/O
usage of the micro controller
