Current Sense, Voltage Input
Basic Features

12V or 24V capable

Single or multi channel
Protection Features

Short circuit shutdown with auto-
restart or latch

Overtemperature shutdown
with auto-restart or latch

Reverse polarity protection by
ReverSave™ or with external
components

Loss of GND
Diagnosis Features

Analog signal proportional to
load current

Overload

Open-load in ON

Overtemperature

Short-circuit to GND
Product Type Product Family R
DS(on)
(typ)
[mΩ]
R
DS(on)
(max)
@ T
j
= 150°C
[mΩ]
Nominal Load
Current
[A]
E
AS
[mJ]
Operating Voltage
Range
[V]
I
L (SC)
(typ)
[A]
Number of
channels
Load Current Over voltage
Shutdown
Sense
Enable
Open-load in
OFF
Latch 24V ReverSave™ Packages
1)
Limit Trip
Automotive Grade
BTS5200-4EKA PROFET™+ 12V 200.0 400.0 4 x 0.8 50 @ 0.5A 5.0 … 28 7.3 4
l l l

5
BTT6200-4EMA
3)
PROFET™+ 24V 200.0 400.0 4 x 1.0 20 @ 1A 5.0 … 36 9.0 4
l l l l l

30
BTT6200-1EJA
3)
PROFET™+ 24V 200.0 400.0 1.5 20 @ 1A 5.0 … 36 9.0 1
l l l l l

2
BTS5180-2EKA PROFET™+ 12V 180.0 360.0 2 x 1.0 30 @ 1A 5.0 … 28 12.0 2
l l l

5
BTS5120-2EKA PROFET™+ 12V 120.0 240.0 2 x 1.0 15 @ 2A 5.0 … 28 12.0 2
l l l

5
BTT6100-2EKA
3)
PROFET™+ 24V 100.0 200.0 2 x 2.2 36 @ 1.5A 5.0 … 36 20.0 2
l l l l l

5
BTS5090-2EKA PROFET™+ 12V 90.0 180.0 2 x 2.0 42 @ 3A 5.0 … 28 32.0 2
l l l

5
BTS5090-1EJA PROFET™+ 12V 90.0 180.0 2.5 42 @ 3A 5.0 … 28 32.0 1
l l l

2
BTS6110-1SJA PROFET™ Motorcycle 80.0 200.0 2.0 n.a. 8.0 … 24 27.0 1
l l

1
BTT6050-1EKA PROFET™+ 24V 50.0 105.0 4.5 55 @ 4A 5.0 … 48 47.0 1
l l l l l

5
BTT6050-2EKA PROFET™+ 24V 50.0 100.0 2 x 3.0 55 @ 4A 5.0 … 48 47.0 2
l l l l l

5
BTS5045-2EKA PROFET™+ 12V 45.0 90.0 2 x 2.5 35 @ 4A 5.0 … 28 32.0 2
l l l

5
BTS5045-1EJA PROFET™+ 12V 45.0 90.0 3 35 @ 4A 5.0 … 28 32.0 1
l l l

2
BTS740S2 Classic PROFET™ 30.0 60.0 4 370 @ 5.5A 5.0 … 34 50.0 2
l l

6
BTS640S2G Classic PROFET™ 30.0 60.0 4.5 410 @ 12.6A 5.0 … 34 50.0 1
l l

38
BTT6030-2EKA PROFET™+ 24V 30.0 64.0 2 x 4.0 50 @ 4A 5.0 … 48 70.0 2
l l l l l

5
BTT6030-1EKA PROFET™+ 24V 30.0 64.0 6.0 50 @ 6A 5.0 … 48 70.0 1
l l l l l

5
BTT6020-1EKA PROFET™+ 24V 20.0 42.0 7.0 100 @ 7A 5.0 … 48 88.0 1
l l l l l

5
BTS5030-2EKA PROFET™+ 12V 30.0 60.0 2 x 3.0 50 @ 6A 5.0 … 28 47.0 2
l l l

5
BTS5030-1EJA PROFET™+ 12V 30.0 60.0 4.0 50 @ 6A 5.0 … 28 47.0 1
l l l

2
BTS5020-2EKA PROFET™+ 12V 20.0 40.0 2 x 4.0 75 @ 6A 5.0 … 28 65.0 2
l l l

5
BTS5020-1EKA PROFET™+ 12V 20.0 40.0 5.0 74 @ 6A 5.0 … 28 65 1
l l l

5
BTS5016-2EKA PROFET™+ 12V 16.0 32.0 2 x 5.0 95 @ 7A 5.0 … 28 65 2
l l l

5
BTS5016-1EKB PROFET™+ 12V 16.0 32.0 6.0 95 @ 7A 5.0 … 28 65 1
l l l

5
BTS5012-1EKB PROFET™+ 12V 12.0 24.0 8.0 110 @ 10A 5.0 … 28 65.0 1
l l l

5
BTS5010-1EKB PROFET™+ 12V 10.0 20.0 9.0 155 @ 10A 5.0 … 28 65.0 1
l l l

5
BTT6010-1EKA
4)
PROFET™+ 24V 10.0 20.0 8.0 100 @ 8A 5.0 … 36 90.0 1
l l l l l

5
BTS5008-1EKB PROFET™+ 12V 8.0 16.0 10.0 160 @ 11A 5.0 … 28 65.0 1
l l l

5
BTS50080-1EGA High-Current PROFET™ 8.0 16.0 13.0 125 @ 50A 6.0 … 28 150 1
l l l l l

3
BTS50070-1EGA High-Current PROFET™ 7.0 14.0 14.0 145 @ 50A 6.0 … 28 150 1
l l l l l

3
BTS50060-1EGA High-Current PROFET™ 6.0 12.0 15.0 170 @ 50A 6.0 … 28 150.0 1
l l l l l

3
BTS50060-1TEA High-Current PROFET™ 6.0 12.0 13.5 280 @ 20A 4.7 … 28 75.0 1
l l l

33
BTF50060-1TEA
2)
High-Current PROFET™ 6.0 12.0 13.5 280 @ 20A 4.7 … 28 75.0 1
l l l

33
BTS50050-1EGA High-Current PROFET™ 5.0 10.0 16.0 200 @ 50A 6.0 … 28 150.0 1
l l l l l

3
BTS50040-2SFA High-Current PROFET™ 4.0 8.2 2 x 11.0 411 @ 20A 6.0 … 28 160.0 2
l l l l

11
BTS50015-1TAA Power PROFET™ 1.5 3.0 39.0 550 @ 33A 5.5 … 28 135.0 1
l l l

38
www.infineon.com/profet
