Current Sense, Current Input
Basic Features

12V or 24V capable

Single channel
Protection Features

Current limitation

Overload protection

Short circuit shutdown

ReverSave™

Loss of GND
Diagnosis Features

Analog signal proportional to
load current

Overload detection

Short circuit detection
Product Type Product Family R
DS(on)
(typ)
[mΩ]
R
DS(on)
(max.)
@ T
j
= 150°C
[mΩ]
Nominal Load
Current
[A]
E
AS
@ 20A
[mJ]
Operating Voltage
Range
[V]
I
L (SC)
(typ)
[A]
24V
Capable
Short-circuit to GND Protection Overtemperature Protection Inverse Current
Operation
Capability
Open-load in ON
Detection
Packages
1)
Latch Restart Latch Restart
BTS6163D High-Current PROFET™ 20.0 40 6.5 250 5.5 … 62 70
l l l l

33
BTS443P High-Current PROFET™ 16.0 32 6.5 150 5.0 … 36 65
l
l l

33
BTS5016SDA High-Current PROFET™ 16.0 32 6.5 120 5.5 … 20 75
l l l

33
BTS5014SDA High-Current PROFET™ 14.0 28 7.0 150 5.5 … 20 80
l l l

33
BTS5012SDA High-Current PROFET™ 12.0 24 8.0 200 5.5 … 20 90
l l l

33
BTS6142D High-Current PROFET™ 12.0 22 8.0 250 5.5 … 24 100
l l l

33
BTS6143D High-Current PROFET™ 10.0 18 10.0 300 5.5 … 38 105
l l l

33
BTS6133D High-Current PROFET™ 10.0 18 10.0 300 5.5 … 38 105
l l l l

33
BTS50085-1TMA High-Current PROFET™ 9.0 17 11.0 1200 5.5 … 58 90
l l l l

39
BTS50085-1TMB High-Current PROFET™ 9.0 17 11.0 1200 5.0 … 58 90
l l l l

55
BTS50080-1TMA High-Current PROFET™ 8.0 16 12.0 400 5.5 … 38 130
l l l

39
BTS50080-1TMB High-Current PROFET™ 8.0 16 12.0 400 5.5 … 38 130
l l l

56
BTS50080-1TMC High-Current PROFET™ 8.0 16 12.0 400 5.5 … 38 130
l l l

39
BTS50080-1TEA High-Current PROFET™ 8.0 16 10.0 300 5.5 … 30 125
l l l

33
BTS50080-1TEB High-Current PROFET™ 8.0 16 10.0 300 5.5 … 30 125
l l l l

33
BTS50070-1TMA High-Current PROFET™ 7.0 14 12.0 400 5.5 … 30 95
l l l

39
BTS50070-1TMB High-Current PROFET™ 7.0 14 12.0 400 5.5 … 30 95
l l l

56
BTS50055-1TMA High-Current PROFET™ 6.0 11 17.0 1500 5.0 … 34 130
l l l

39
BTS50055-1TMB High-Current PROFET™ 6.0 11 17.0 1500 5.0 … 34 130
l l l

55
BTS50055-1TMC High-Current PROFET™ 6.0 11 17.0 1500 5.5 … 34 130
l l l

39
BTS550P High-Current PROFET™ 3.5 6.5 35.0 3000 5.0 … 34 220
l l l

51
BTS555 High-Current PROFET™ 2.5 4 45.0 3000 5.0 … 34 400
l l l

51
www.infineon.com/profet
