Digital Diagnosis
Basic Features

12V or 24V capable

Single or multi channel
Protection Features

Overload protection

Loss of battery / GND

Short circuit protection

Overvoltage protection
Diagnosis Features

Open drain status feedback

Overtemperature

Open load

Current limitation
Product Type Product Family R
DS(on)
(typ)
[mΩ]
R
DS(on)
(max.)
@ T
j
= 150°C
[mΩ]
Nominal Load
Current
[A]
E
AS
[mJ]
Operating Voltage
Range
[V]
I
L (SC)
(typ)
[A]
Number
of
Channels
24V Capable High Current
Limit
Low Current
Limit
Overvoltage
Shutdown
Short Circuit Diagnosis Packages
1)
to GND to battery Open Load in
ON-State
Automotive Grade
BSP742R Classic PROFET™ 350 700 0.4 800 @ 0.3A 5.0 … 34 1.2 1
l l l

1
BSP742RI
2)
Classic PROFET™ 350 700 0.4 800 @ 0.3A 5.0 … 34 1.2 1
l l l

1
BTS4300SGA Classic PROFET™ 300 600 0.4 800 @ 0.3A 5.0 … 34 1.2 1
l l l

1
BSP752R Classic PROFET™ 200 380 1.7 125 @ 1.0A 6.0 … 52 6.5 1
l l l l

1
BTS712N1 Classic PROFET™ 200 400 1.0 150 @ 1.9 A 5.0 … 34 7.5 4
l l l

6
BTS711L1 Classic PROFET™ 200 400 1.0 150 @ 1.9 A 5.0 … 35 7.5 4
l l l l

6
BTS4880-R Classic PROFET™ 200 400 0.6 10000 @ 0.625A 11.0 … 45 1.4 8
l l

13
BTS4175SGA Classic PROFET™ 175 350 1.3 125 @ 1.0A 6.0 … 52 6.5 1
l l l l

1
BTS4160DGA Classic PROFET™ 160 320 1.0 65 @ 2.9A 5.5 … 20 9.0 2
l l

4
BTS452R Classic PROFET™ 150 270 2.2 150 @ 1.0A 6.0 … 52 6.5 1
l l l l

33
BTS5210G Classic PROFET™ 140 280 1.0 65 @ 2.9A 5.5 … 40 9.0 2
l l

4
BTS5210L Classic PROFET™ 140 280 1.0 84 @ 2.9A 5.5 … 40 9.0 2
l l

3
BTS716G Classic PROFET™ 140 280 1.0 76 @ 2.3A 5.5 … 40 9.0 4
l l

6
BTS716GB Classic PROFET™ 140 280 1.0 76 @ 2.3A 5.5 … 40 9.0 4
l l

6
BTS4130QGA Classic PROFET™ 130 260 1.0 76 @ 2.3A 5.5 … 20 9.0 4
l l

6
BTS723GW Classic PROFET™ 105 210 2.0 110 @ 2.5A 7.0 … 58 9.0 2
l l l l

4
BTS721L1 Classic PROFET™ 100 200 2.0 300 @ 2.9A 5.0 … 34 14.0 4
l l l

6
BTS5215L Classic PROFET™ 90 180 2.0 178 @ 3.5A 5.5 … 40 15.0 2
l l

3
BTS724G Classic PROFET™ 90 180 2.0 120 @ 3.3A 5.5 … 40 15.0 4
l l

6
BTS428L2 Classic PROFET™ 60 120 7.0 190 @ 7.0A 4.75 … 41 22.0 1
l l l

33
BTS432E2 High-Current PROFET™ 38 70 11.0 1700 @ 20.0A 4.5 … 42 44.0 1
l l l l l

53
BTS432E2 E3062A High-Current PROFET™ 38 70 11.0 1700 @ 20.0A 4.5 … 42 44.0 1
l l l l l

36
BTS441R Classic PROFET™ 20 37 21.0 700 @ 21.0A 4.75 … 41 65.0 1
l l

36
BTS442E2 High-Current PROFET™ 18 35 21.0 2100 @ 20.0A 4.5 … 42 95.0 1
l l l l l

53
BTS442E2 E3062A High-Current PROFET™ 18 35 21.0 2100 @ 20.0A 4.5 … 42 95.0 1
l l l l l

36
