SPIDER Product Table
Product Type High-Side Small High-Side Low-Side Configurable R
DS(on)
(typ)
@25°C [Ω]
Cranking Mode
[V]
V
DS(AZ)
[V]
Limp Home I
L(nom)
[mA]
Number of Direct
Inputs
Package
1)
SPIDER LS
TLE7230R – – 8 – 0.8 – 48 500 4

13
TLE7240SL – – 8 – 1.5 – 41
l
210 4

29
TLE7243SL – – 8 – 1.2 – 41
l
260 4

29
TLE7244SL – – 8 – 0.8 – 41
l
290 4

29
TLE7231G – – 4 – 1.0 – 41 320 1

4
TLE7233G – – 4 – 1.0 – 41
l
390 4

29
SPIDER HS/LS
TLE7237SL 2 2 2 2 6 x 0.9; 2 x 1.6 – 41 6 x 260; 2 x 120 3

29
TLE7238SL 2 2 2 2 6 x 0.9; 2 x 1.6 – 41
l
6 x 260; 2 x 120 2

29
TLE7239SL 2 2 2 2 6 x 0.9; 2 x 1.6 4 41
l
6 x 260; 2 x 120 2

29
TLE7234SE 2 2 2 2 6 x 0.85; 2 x 1.6 – 41 6 x 280; 2 x 140 3

6
TLE7235SE 2 2 2 2 6 x 0.85; 2 x 1.6 – 41
l
6 x 280; 2 x 140 2

6
TLE7236SE 2 2 2 2 6 x 0.85; 2 x 1.6 4 41
l
6 x 280; 2 x 140 2

6
TLE7234EM 2 2 2 2 6 x 0.9; 2 x 1.6 – 41 6 x 350; 2 x 175 3

30
TLE7235EM 2 2 2 2 6 x 0.9; 2 x 1.6 – 41
l
6 x 350; 2 x 175 2

30
TLE7236EM 2 2 2 2 6 x 0.9; 2 x 1.6 4 41
l
6 x 350; 2 x 175 2

30
