1) See packages on page 112
2) Non green, discontinued. Replacement in development: BTS3018TC (Available in December 2014)
33
Product Table HITFET™: Low-Side Protected Switches
Product Type R
DS(on)
[mΩ]
Channels V
DS(AZ)
[V]
I
L(nom)
[A]
I
L(lim)
[A]
PWM
[kHz]
Diagnostic Package
1)
BTS3160D 10 1 40 7.8 70.0 1 digital

33
BTS3256D 10 1 40 7.5 42.0 10 digital

33
BTS3142D 28 1 42 4.6 30.0 1 through input pin

32
BTS142D 28 1 42 4.6 30.0 1 through input pin

32
BTS3134N 50 1 42 3.0 18.0 1 through input pin

23
BTS3134D 50 1 42 3.5 18.0 1 through input pin

32
BSP78 50 1 42 3.0 18.0 1 through input pin

23
BTF3050TE 50 1 40 3.0 30 (8) 10 through SRP pin

33
BTS134D 50 1 42 3.5 18.0 1 through input pin

52
BTS3118D 100 1 42 2.4 10.0 1 through input pin

32
BTS3118N 100 1 42 2.2 10.0 1 through input pin

23
BSP77 100 1 42 2.2 10.0 1 through input pin

23
BTS118D 100 1 42 2.4 10.0 1 through input pin

32
BSP76 200 1 42 1.4 5.0 1 through input pin

23
BTS3410G 200 2 42 1.3 5.0 1 through input pin

1
BTS3110N 200 1 42 1.4 5.0 1 through input pin

23
BTS3207N 500 1 42 0.7 5.0 1 through input pin

23
BTS3205G 700 1 42 0.35 0.6 1 through input pin

1
BTS3405G 700 2 42 0.35 0.6 1 through input pin

1
BTS3205N 700 1 42 0.35 0.6 1 through input pin

23
BTS3800SL 800 1 42 0.35 0.6 10

20
BTS149
2)
20 1 60 6.4 30.0 1 through input pin

52
BTS141TC 30 1 60 5.1 25.0 1 through input pin

34
BTS3028SDL 30 1 60 5.0 18.0 1 through input pin

32
BTS3028SDR 30 1 60 5.0 18.0 1 through input pin

32
BTS133TC 50 1 60 3.8 21.0 1 through input pin

34
BTS3046SDL 50 1 60 3.6 10.0 1 through input pin

32
BTS3046SDR 50 1 60 3.6 10.0 1 through input pin

32
BTS117TC 100 1 60 3.5 7.0 1 through input pin

34
BTS3104SDL 104 1 60 2.0 6.0 1 through input pin

32
BTS3104SDR 104 1 60 2.0 6.0 1 through input pin

32
BSP75N 550 1 60 0.7 1.0 5 through input pin

23
BTS3408G 550 2 60 0.55 1.0 1 through input pin

1
