Product Table TEMPFET™: Temperature Protected Switches
Product Type V
DS
[V]
R
DS(on)
[mΩ]
I
D
[A]
V
GS(th)
(min-max)
[V]
Q
G
(typ)
[nC]
Package
1)
BTS282Z 49 6.5 80 1.2 … 2.0 155

39

55
BTS244Z 55 12.0 35 1.2 … 2.0 85

37

53

54
BTS247Z 55 18.0 33 1.2 … 2.0 60

37

53

54
TEMPFET™ provides the first level of temperature and
current protection via its temperature sensor.
The temperature sensor is available on external pins
and enables direct gate access and flexible temperature
response control.
Features

Logic level input

Analog driving capability

Potential-free temperature sensor

High-speed switching (100kHz)

Overload protection and thermal shutdown
with external circuit

Avalanche rated
www.infineon.com/tempfet
1) See packages on page 112
