29
1) See packages on page 112
Example for Automotive Topology using CoolMOS™ CFDA
CoolMOS™ CPA 4x CoolMOS™ CFDA
V
AC
V
Battery
N:1
Bridge Rectifier PFC Stage DC/DC Stage
On-board battery charger with ZVS phase shied topology
600V CoolMOS™ CPA Product Portfolio
Product Type R
DS(on)
@ T
J
= 25°C
V
GS
= 10V
[mΩ]
I
D
(max) @
T
J
= 25°C
[A]
I
Dpuls
(max)
[A]
V
GS(th)
(min-max)
[V]
Q
G
(typ)
[nC]
R
thJC
(max)
[K/W]
Package
1)
IPB60R099CPA 105 31 93 -20 … 20 60 0.5
34
IPB60R199CPA 199 16 51 -20 … 20 32 0.9
34
IPB60R299CPA 299 11 34 -20 … 20 22 1.3
34
IPP60R099CPA 105 31 93 -20 … 20 60 0.5
52
IPW60R045CPA 45 60 230 -20 … 10 150 0.29
58
IPW60R075CPA 75 39 130 -20 … 20 87 0.4
58
IPW60R099CPA 105 31 93 -20 … 20 60 0.5
58
IPI60R099CPA 105 31 93 -20 … 20 60 0.5
59
650V CoolMOS™ CFDA Product Portfolio
Product Type R
DS(on)
@ T
J
= 25°C
V
GS
= 10V
[mΩ]
I
D
(max) @
T
J
= 25°C
[A]
I
Dpuls
(max)
[A]
V
GS(th)
(min-max)
[V]
Q
G
(typ)
[nC]
R
thJC
(max)
[K/W]
Package
1)
IPD65R420CFDA 420 8.7 27.0 3.5 … 4.5 32 1.5
32
IPD65R660CFDA 660 6.0 17.0 3.5 … 4.5 20 2.0
32
IPB65R110CFDA 110 31.2 99.6 3.5 … 4.5 118 0.45
34
IPB65R150CFDA 150 22.4 72.0 3.5 … 4.5 86 0.64
34
IPB65R190CFDA 190 17.5 57.2 3.5 … 4.5 68 0.83
34
IPB65R310CFDA 310 11.4 34.4 3.5 … 4.5 41 1.2
34
IPB65R660CFDA 660 6.0 17.0 3.5 … 4.5 20 2.0
34
IPP65R110CFDA 110 31.2 99.6 3.5 … 4.5 118 0.45
52
IPP65R150CFDA 150 22.4 72.0 3.5 … 4.5 86 0.64
52
IPP65R190CFDA 190 17.5 57.2 3.5 … 4.5 68 0.83
52
IPP65R310CFDA 310 11.4 34.4 3.5 … 4.5 41 1.2
52
IPP65R660CFDA 660 6.0 17.0 3.5 … 4.5 20 2.0
52
IPW65R048CFDA 48 63.3 228.0 3.5 … 4.5 270 0.25
58
IPW65R080CFDA 80 43.3 127.0 3.5 … 4.5 161 0.32
58
IPW65R110CFDA 110 31.2 99.6 3.5 … 4.5 118 0.45
58
IPW65R150CFDA 150 22.4 72.0 3.5 … 4.5 86 0.64
58
IPW65R190CFDA 190 17.5 57.2 3.5 … 4.5 68 0.83
58
www.infineon.com/CFDA
