Power MOSFETs
600V CoolMOS™ CPA and 650V CoolMOS™ CFDA
www.infineon.com/CFDA
IPP60R099 CPA
Infineon
P
ower MOSFET
P
ackage Type
B
= PG-TO263 (D
2
PAK)
I
= PG-TO262 (I
2
PAK)
P
= PG-TO220
W
= PG-TO247
Breakdown Voltage
Divided by 10 (60 x 10 = 600V)
Automotive
Series Name
CoolMOS™ CP and CoolMOS™ CFD
R
DS(on)
[m]
R = R
DS(on)
Naming System
Aer launching the first series of high voltage automotive
MOSFET the 600V CoolMOS™ CPA series, Infineon has
launches its second generation of market leading
Automotive qualified high voltage MOSFET the 650V
CoolMOS™ CFDA series. Were the first generation of 600V
CoolMOS™ CPA series addresses the well-known
attributes of high quality and reliability required by the
automotive industry, the new 650V CoolMOS™ CFDA
series additional caters to special application needs with
its integrated Fast Body Diode. This Fast Body Diode is
the key for addressing resonant switching topologies
resulting in lower switching losses due to the low gate
charge. The soer commutation behavior and consequent
reduced EMI appearance gives the 650V CoolMOS™ CFDA
series a clear advantage in comparison with competitor
parts. Furthermore, limited voltage overshoot during
Common Key Features CoolMOS™ “A”

First 600V/650V automotive qualified high voltage
technologies for automotive market

Compliant to AEC Q101 standard
Key features 600V CoolMOS™ CPA

Lowest Rdson per package

Lowest gate charge value Q
g
Key feature 650V CoolMOS™ CFDA

Limited voltage overshoot during hard commutation –
self-limiting di/dt and dv/dt

Low Q
rr
at repetitive commutation on body diode & low Q
oss
hard commutation of the body diode enables easier
implementation of layout and design.
The basic 600V CoolMOS™ CPA portfolio is now
complemented with the broad 650V CoolMOS™ CFDA
portfolio which provides all benefits of fast switching
Super junction MOSFET fulfilling the enhanced reliability
requirements for automotive applications realized with
special screening measures in Front End and Back End as
well as the qualification compliant to AEC Q100.
Therefore, the combination of both technologies the
600V CoolMOS™ CPA and the new 650V CoolMOS™ CFDA
technology is the best choice for switching topologies in
Automotive applications.
Applications 600V CoolMOS™ CPA

Hard switching topologies

PFC boost stages in on board charger

Active clamp or 2 transistor forward in DC/DC converter
Application 650V CoolMOS™ CFDA

Resonant switching topologies

LLC or Full Bridge ZVS in DC/DC converter

HID lamp
