Voltage Product Type R
DS(on)
(max)
@ V
GS
= -10V
[mΩ]
I
D
[A]
V
GS(th)
(min-max)
[V]
Q
G
(typ)
[nC]
Technology Package
1)
-100V
BSP322P 800 -1.0 -2.0 … -1.0 -12.4 SIPMOS™

23
BSP321P 900 -0.98 -4.0 … -2.1 -9.0 SIPMOS™

23
BSP316P 1,800 -0.68 -2.0 … -1.0 -5.1 SIPMOS™

23
BSR316P 1,800 -0.36 -2.0 … -1.0 -3.0 SIPMOS™

18
-250V
BSP317P 4,000 -0.43 -2.0 … -1.0 -11.6 SIPMOS™

23
BSP92P 12,000 -0.26 -2.0 … -1.0 -4.3 SIPMOS™

23
BSS192P 12,000 -0.19 -2.0 … -1.0 -4.9 SIPMOS™

22
BSR92P 11,000 -0.14 -2.0 … -1.0 -3.6 SIPMOS™

18
Complementary MOSFETs
Voltage Product Type R
DS(on)
(max)
@ V
GS
= -10V
[mΩ]
I
D
[A]
V
GS(th)
(min-max)
[V]
Q
G
(typ)
[nC]
Technology Package
1)
20V BSL215C/n-ch – 1.5 0.7 … 1.2 0.73 OptiMOS™2

46
(dual)
-20V BSL215C/p-ch – -1.5 -1.2 … -0.6 -3.0 OptiMOS™2 P

46
(dual)
20V BSD235C/n-ch – 0.95 -1.2 … -0.6 0.34 OptiMOS™2

26
(dual)
-20V BSD235C/p-ch – -0.53 0.7 … 1.2 -0.4 OptiMOS™2 P

26
(dual)
20V BSZ15DC02KD/n-ch – 5.1 0.8 … 1.4 2.1 OptiMOS™2

42
(dual)
-20V BSZ15DC02KD/p-ch – -3.2 -1.4 … -0.7 -3.0 OptiMOS™2 P

42
(dual)
30V BSL316C/n-ch 160 1.4 -2.0 … -1.0 0.6 OptiMOS™2

46
(dual)
-30V BSL316C/p-ch 150 -1.5 1.2 … 2.0 -2.4 OptiMOS™2 P

46
(dual)
30V BSL308C/n-ch 57 2.3 1.2 … 2.0 1.5 OptiMOS™2

46
(dual)
-30V BSL308C/p-ch 80 -2.1 -2.0 … -1.0 -2.9 OptiMOS™3 P

46
(dual)
30V BSD356C/n-ch
2)
350 0.95 4.5 – OptiMOS™2

26
(dual)
-30V BSD356C/p-ch
2)
560 -0.73 4.5 – OptiMOS™2 P

26
(dual)
Depletion MOSFETs
Voltage Product Type R
DS(on)
(max)
@ V
GS
= 0V
[mΩ]
I
D
[A]
Q
G
(typ)
[nC]
Technology Package
1)
60V BSS159N 8.0 0.13 2.2 SIPMOS™

21
100V BSS169 12.0 0.09 2.1 SIPMOS™

21
200V BSP149 3.5 0.14 11.0 SIPMOS™

23
240V BSP129 20.0 0.05 3.8 SIPMOS™

23
250V BSS139 30.0 0.03 2.3 SIPMOS™

21
600V
BSP135 60.0 0.02 3.7 SIPMOS™

23
BSS126 700.0 0.007 1.4 SIPMOS™

21
1) See packages on page 112
2) Coming Q2/2015
www.infineon.com/smallsignalmosfets
www.infineon.com/complementary
www.infineon.com/pchannel
www.infineon.com/depletion
