26
Voltage Product Type R
DS(on)
(max)
[mΩ]
I
D
[A]
V
GS(th)
(min-max)
[V]
Q
G
(typ)
[nC]
Technology Package
1)
400V
BSP298 3,000 0.5 2.1 … 4.0 – SIPMOS™
23
BSP324 25,000 0.17 1.3 … 2.3 4.5 SIPMOS™
23
500V BSP299 4,000 0.4 2.1 … 4.0 – SIPMOS™
23
600V
BSP125 45,000 0.12 1.3 … 2.3 4.4 SIPMOS™
23
BSS225 45,000 0.09 1.3 … 2.3 3.9 SIPMOS™
22
BSS127 500,000 0.023 1.4 … 2.6 1.4 SIPMOS™
21
800V BSP300 20 0.19 2.1 … 4.0 – SIPMOS™
23
P-Channel MOSFETs
Voltage Product Type R
DS(on)
(max)
@ V
GS
= -10V
[mΩ]
I
D
[A]
V
GS(th)
(min-max)
[V]
Q
G
(typ)
[nC]
Technology Package
1)
-20V
BSL207SP – -6.0 -1.2 … -0.6 -13.3 OptiMOS™2 P
46
BSL211SP – -4.7 -1.2 … -0.6 -8.3 OptiMOS™2 P
46
BSL215P – -1.5 -1.2 … -0.6 -3.55 OptiMOS™2 P
46
(dual)
BSS215P – -1.5 -1.2 … -0.5 -3.6 OptiMOS™2 P
21
BSS209PW – -0.58 -1.2 … -0.6 -0.92 OptiMOS™2 P
24
BSS223PW – -0.39 -1.2 … -0.6 -0.5 OptiMOS™2 P
24
BSV236SP – -1.5 -1.2 … -0.6 -3.8 OptiMOS™ P
26
BSD223P – -0.39 -1.2 … -0.6 -0.5 OptiMOS™2 P
26
(dual)
-30V
BSL307SP 43 -5.5 -2.0 … -1.0 -23.4 OptiMOS™2 P
46
BSL308PE 80 -2.1 -2.0 … -1.0 -2.9
OptiMOS™3 P +
integrated ESD diode
46
(dual)
BSL314PE 140 -1.5 -2.0 … -1.0 -2.3
OptiMOS™3 P +
integrated ESD diode
46
(dual)
BSL315P 150 -1.5 -2.0 … -1.0 -2.3 OptiMOS™2 P
46
(dual)
BSS308PE 80 -2.1 -2.0 … -1.0 -5.2
OptiMOS™3 P +
integrated ESD diode
21
BSS314PE 140 -1.5 -2.0 … -1.0 -2.9
OptiMOS™3 P +
integrated ESD diode
21
BSS315P 150 -1.5 -2.0 … -1.0 -2.3 OptiMOS™2 P
21
BSD314SPE 140 -1.5 -2.0 … -1.0 -2.9
OptiMOS™3 P +
integrated ESD diode
26
BSL303SPE 30 -6.6 4.5 –
OptiMOS™ P +
integrated ESD diode
46
BSL305SPE 50 -5.3 4.5 –
46
BSS356PWE
2)
560 -0.73 4.5 –
24
BSD356PE
2)
560 -0.73 4.5 –
26
-60V
BSP613P 130 -2.9 -4.0 … -2.1 -22.0 SIPMOS™
23
BSP170P 300 -1.9 -4.0 … -2.1 -10.0 SIPMOS™
23
-60V
BSP171P 300 -1.9 -2.0 … -1.0 -13.0 SIPMOS™
23
BSP315P 800 -1.17 -2.0 … -1.0 -5.2 SIPMOS™
23
BSR315P 800 -0.62 -2.0 … -1.0 -4.0 SIPMOS™
18
BSS83P 2,000 -0.33 -2.0 … -1.0 -2.38 SIPMOS™
21
BSS84P 8,000 -0.17 -2.0 … -1.0 -1.0 SIPMOS™
21
BSS84PW 8,000 -0.15 -2.0 … -1.0 -1.0 SIPMOS™
24
Small Signal MOSFETs
1) See packages on page 112
2) Coming Q2/2015
www.infineon.com/smallsignalmosfets
www.infineon.com/complementary
www.infineon.com/pchannel
www.infineon.com/depletion
N-Channel MOSFETs (cont’d)
