N-Channel MOSFETs
Voltage Product Type R
DS(on)
(max)
[mΩ]
I
D
[A]
V
GS(th)
(min-max)
[V]
Q
G
(typ)
[nC]
Technology Package
1)
20V
BSL802SN – 7.5 0.3 ... 0.75 4.7 OptiMOS™2

46
BSL202SN – 7.5 0.7 ... 1.2 5.8 OptiMOS™2

46
BSL205N – 2.5 0.7 ... 1.2 2.1 OptiMOS™2

46
(dual)
BSL214N – 1.5 0.7 ... 1.2 0.8 OptiMOS™2

46
(dual)
BSL207N – 2.1 0.7 ... 1.2 2.1 OptiMOS™2

46
(dual)
BSL806N – 2.3 0.3 ... 0.75 1.7 OptiMOS™2

46
(dual)
BSR202N – 3.8 0.7 ... 1.2 5.8 OptiMOS™2

18
BSR802N – 3.7 0.3 ... 0.75 4.7 OptiMOS™2

18
BSS205N – 2.5 0.7 ... 1.2 2.1 OptiMOS™2

21
BSS214N – 1.5 0.7 ... 1.2 0.8 OptiMOS™2

21
BSS806N – 2.3 0.3 ... 0.75 1.7 OptiMOS™2

21
BSS816NW – 1.4 0.3 ... 0.75 0.6 OptiMOS™2

24
BSS214NW – 1.5 0.7 ... 1.2 0.8 OptiMOS™2

24
BSD214NW – 1.5 0.7 ... 1.2 0.8 OptiMOS™2

26
BSD816SN – 1.4 0.3 ... 0.75 0.6 OptiMOS™2

26
BSD235N – 0.95 0.7 ... 1.2 0.32 OptiMOS™2

26
(dual)
BSD840N – 0.88 0.3 ... 0.75 0.26 OptiMOS™2

26
(dual)
30V
BSR302N 23 3.7 1.2 ... 2.0 4.4 OptiMOS™2

18
BSL302SN 25 7.1 1.2 ... 2.0 4.4 OptiMOS™2

46
BSL306N 57 2.3 1.2 ... 2.0 1.6 OptiMOS™2

46
(dual)
BSS306 57 2.3 1.2 … 2.0 1.5 OptiMOS™2

21
BSS316N 160 1.4 1.2 … 2.0 0.6 OptiMOS™2

21
BSD316SN 160 1.4 1.2 ... 2.0 0.6 OptiMOS™2

26
55V
BSS670S2L 650 0.54 1.2 … 2.0 1.7 OptiMOS™

21
60V
BSS606N 60 3.2 1.3 … 2.3 6.1 OptiMOS™3

22
BSL606SN 60 4.5 1.3 … 2.3 6.1 OptiMOS™3

46
BSR606N 60 2.4 1.3 … 2.3 6.1 OptiMOS™3

18
BSP318S 90 2.6 1.2 … 2.0 14.0 SIPMOS™

23
BSP320S 120 2.9 2.1 … 4.0 9.7 SIPMOS™

23
BSP295 300 1.8 0.8 … 1.8 14.0 SIPMOS™

23
2N7002DW 3,000 0.3 1.5 ... 2.5 0.4 OptiMOS™

26
(dual)
BSS138N 3,500 0.23 0.6 … 1.4 1.0 SIPMOS™

21
BSS138W 3,500 0.28 0.6 … 1.4 1.0 SIPMOS™

23
SN7002N 5,000 0.2 0.8 … 1.8 1.0 SIPMOS™

21
BSS7728N 5,000 0.2 1.3 … 2.3 1.0 SIPMOS™

21
SN7002W 5,000 0.23 0.8 … 1.8 1.0 SIPMOS™

24
100V
BSL372SN 220 2.0 4.5 9.5 SIPMOS™

46
BSP372N 230 1.8 0.8 … 2.0 9.5 SIPMOS™

23
BSL373SN 230 2.0 10.0 6.2 SIPMOS™

46
BSP373N 240 1.8 2.1 … 4.0 6.2 SIPMOS™

23
BSL296SN 460 1.4 4.5 4.5 SIPMOS™

46
BSP296N 600 1.2 0.8 … 1.8 4.5 SIPMOS™

23
BSS123N 6,000 0.19 0.8 … 1.8 0.6 SIPMOS™

21
BSS119N 6,000 0.19 1.8 … 2.3 0.6 SIPMOS™

21
200V
BSP297 1,800 0.66 0.8 … 1.8 12.9 SIPMOS™

23
240V
BSP89 6,000 0.35 0.8 … 1.8 4.3 SIPMOS™

23
BSP88 6,000 0.35 0.6 … 1.4 4.5 SIPMOS™

23
BSS87 6,000 0.26 0.8 … 1.8 3.7 SIPMOS™

22
BSS131 14,000 0.11 0.8 … 1.8 2.1 SIPMOS™

21
www.infineon.com/smallsignalmosfets
www.infineon.com/complementary
www.infineon.com/pchannel
www.infineon.com/depletion
1) See packages on page 112
