Small Signal MOSFETs
The portfolio includes:
Polarity: N-Channel enhancement, N-Channel
depletion and P-Channel MOSFETs
Voltage classes: -250 ... 800V
V
GS
rating: 10V (Normal Level), 4.5V (Logic Level),
2.5V (Super Logic Level), 1.8V (Ultra Logic Level)
Packages: SOT223, SOT89, TSOP-6 (single and dual),
SC59, SOT23, SOT323, SOT363 (single and dual)
Infineon oers a full range of Small Signal MOSFETs qualified according AEC Q101.
Configuration: single, dual, complementary (n+p pairs)
Additional features: the products with names ending with
“E” have an Integrated ESD protection
SC59 is an enhanced version of the SOT23: it’s footprint
compatible with SOT23, but allows a bigger chip inside,
therefore a lower R
DS(on)
.
BSS
159
N
Package Type
BSD/V for SOT363
BSL for TSOP-6
BSP for SOT223
BSR for SC59
BSS for SOT23, SOT89
BSS...W for SOT323
SN for SOT23, SOT323
Sequential Number
3 or 4 digits
Additional Information
0 – 3 digits
N = N-Channel
P = P-Channel
C = Complementary
W = SOT323
S = Single
S2L = OptiMOS™
E = ESD Protection
Naming System
www.infineon.com/smallsignalmosfets
www.infineon.com/complementary
www.infineon.com/pchannel
www.infineon.com/depletion
