OptiMOS™-T2 Dual N-Channel 60V
Product Type R
DS(on)
(max) @ 10V
[mΩ]/channel
I
D
[A]/channel
R
thJC
(max)
[K/W]
V
GS(th)
(min-max)
[V]
Q
G
(typ)
[nC]
Package
1)
IPG20N06S4-15 2 x 15.5 20 3.0 2.0 … 4.0 22

31
IPG20N06S4-15A
2)
NEW!
2 x 15.5 20 3.0 2.0 … 4.0 22

31
IPG20N06S4L-11 2 x 11.1 20 2.3 1.2 … 2.2 41

31
IPG20N06S4L-11A
2)
NEW!
2 x 11.1 20 2.3 1.2 … 2.2 41

31
IPG20N06S4L-14 2 x 13.7 20 3.0 1.2 … 2.2 30

31
IPG20N06S4L-14A
NEW!
2 x 13.7 20 3.0 1.2 … 2.2 30

31
IPG20N06S4L-26 2 x 26.0 20 4.5 1.2 … 2.2 20

31
IPG20N06S4L-26A
NEW!
2 x 26.0 20 4.5 1.2 … 2.2 20

31
OptiMOS™-T2 Dual N-Channel 100V
Product Type R
DS(on)
(max) @ 10V
[mΩ]/channel
I
D
[A]/channel
R
thJC
(max)
[K/W]
V
GS(th)
(min-max)
[V]
Q
G
(typ)
[nC]
Package
1)
IPG20N10S4-36A
NEW!
2 x 36 20 3.5 2.0 … 3.5 9.4

31
IPG16N10S4-61 2 x 61 16 5.2 2.0 … 3.5 5.4

31
IPG16N10S4-61A
NEW!
2 x 61 16 5.2 2.0 … 3.5 5.4

31
IPG20N10S4L-22 2 x 22 20 2.5 1.1 … 2.1 21.0

31
IPG20N10S4L-22A
NEW!
2 x 22 20 2.5 1.1 … 2.1 21.0

31
IPG20N10S4L-35 2 x 35 20 3.5 1.1 … 2.1 13.4

31
IPG20N10S4L-35A
NEW!
2 x 35 20 3.5 1.1 … 2.1 13.4

31
IPG16N10S4L-61A
NEW!
2 x 61 16 5.2 1.1 … 2.1 8.5

31
TWIN MOSFETs
OptiMOS™-T2 TWIN N-Channel 40V
Product Type R
DS(on)
(max) @ 10V
[mΩ]/channel
I
D
[A]/channel
R
thJC
(max)
[K/W]
V
GS(th)
(min-max)
[V]
Q
G
(typ)
[nC]
Package
1)
ITD50N04S4L-07
NEW!
7.2 50 3.2 1.2 … 2.2 25

33
Automotive Dual MOSFETs
1) See packages on page 112
2) Coming Q4/2014
