OptiMOS™-P2 30V P-Channel (Trench)
Product Type R
DS(on)
[mΩ]
I
D
[A]
R
thJC
(max)
[K/W]
V
GS(th)
(min-max)
[V]
Q
G
(typ)
[nC]
Package
1)
IPD90P03P4L-04 4.5 -90 1.1 -2.0 … -1.0 100

32
IPD90P03P4-04 4.5 -90 1.1 -4.0 … -2.0 100

32
IPD80P03P4L-07 6.8 -80 1.7 -2.0 … -1.0 80

32
IPD50P03P4L-11 10.5 -50 2.6 -2.0 … -1.0 42

32
IPB80P03P4L-04 4.1 -80 1.1 -2.0 … -1.0 125

34
IPB80P03P4-05 4.7 -80 1.1 -4.0 … -2.0 100

34
IPB80P03P4L-07 6.9 -80 1.7 -2.0 … -1.0 63

34
IPB45P03P4L-11 10.8 -45 2.6 -2.0 … -1.0 42

34
IPI80P03P4L-04 4.4 -80 1.1 -2.0 … -1.0 125

59
IPI80P03P4L-07 7.2 -80 1.7 -2.0 … -1.0 63

59
IPI45P03P4L-11 11.1 -45 2.6 -2.0 … -1.0 42

59
IPP80P03P4L-04 4.4 -80 1.1 -2.0 … -1.0 125

52
IPP80P03P4L-07 7.2 -80 1.7 -2.0 … -1.0 63

52
IPP45P03P4L-11 11.1 -45 2.6 -2.0 … -1.0 42

52
OptiMOS™-P2 40V P-Channel (Trench)
Product Type R
DS(on)
[mΩ]
I
D
[A]
R
thJC
(max)
[K/W]
V
GS(th)
(min-max)
[V]
Q
G
(typ)
[nC]
Package
1)
IPB180P04P4L-02 2.4 -100 1.0 -2.2 … -1.7 220

38
IPB180P04P4-03 2.8 -100 1.0 -4.0 … -2.0 190

34
IPB120P04P4L-03 3.0 -120 1.1 -2.2 … -1.7 180

34
IPB120P04P4-04 3.6 -120 1.1 -4.0 … -2.0 158

34
IPB80P04P4L-04 4.2 -90 1.2 -2.2 … -1.7 135

34
IPB80P04P4-05 4.9 -80 1.2 -4.0 … -2.0 118

34
IPB80P04P4L-06 6.4 -80 1.7 -2.2 … -1.7 71

34
IPB80P04P4-07 7.3 -80 1.7 -4.0 … -2.0 71

34
IPB70P04P4L-08 7.5 -70 2.0 -2.2 … -1.7 63

34
IPB70P04P4-09 9.3 -70 2.0 -4.0 … -2.0 54

34
IPD90P04P4L-04 4.3 -90 1.2 -2.2 … -1.7 135

32
IPD90P04P4-05 4.7 -90 1.2 -4.0 … -2.0 118

32
IPD85P04P4L-06 6.4 -85 1.7 -2.2 … -1.7 80

32
IPD85P04P4-07 7.3 -85 1.7 -4.0 … -2.0 69

32
IPD70P04P4L-08 7.8 -70 2.0 -2.2 … -1.7 63

32
IPD70P04P4-09 8.9 -70 2.0 -4.0 … -2.0 54

32
IPD50P04P4L-11 10.6 -50 2.6 -2.2 … -1.7 45

32
IPD50P04P4-13 12.7 -50 2.6 -4.0 … -2.0 39

32
IPP120P04P4L-03 3.4 -120 1.1 -2.2 … -1.7 180

52
IPP120P04P4-04 3.9 -120 1.1 -4.0 … -2.0 158

52
IPP80P04P4L-04 4.7 -80 1.2 -2.2 … -1.7 16

52
IPP80P04P4-05 5.2 -80 1.2 -4.0 … -2.0 14

52
IPP80P04P4L-06 6.7 -80 1.7 -2.2 … -1.7 71

52
IPP80P04P4-07 7.6 -80 1.7 -4.0 … -2.0 71

52
IPP80P04P4L-08 7.9 -80 2.0 -1.2 … -2.2 71

59
IPP70P04P4L-08 8.2 -70 2.0 -2.2 … -1.7 63

52
IPP70P04P4-09 9.4 -70 2.0 -4.0 … -2.0 54

52
www.infineon.com/automotivemosfet
1) See packages on page 112
Automotive P-Channel MOSFETs
