1) See packages on page 112
www.infineon.com/automotivemosfet
Automotive N-Channel MOSFETs
OptiMOS™-T2 80V (Trench)
Product Type R
DS(on)
[mΩ]
I
D
[A]
R
thJC
(max)
[K/W]
V
GS(th)
(min-max)
[V]
Q
G
(typ)
[nC]
Package
1)
IPD90N08S4-05
NEW!
5.3 90 1.0 2.0 … 4.0 68

32
IPD50N08S4-13
NEW!
13.2 50 2.1 2.0 … 4.0 30

32
IPB180N08S4-02
NEW!
2.2 180 0.5 2.0 … 4.0 167

38
IPB160N08S4-03
NEW!
3.2 160 0.7 2.0 … 4.0 112

38
IPB140N08S4-04
NEW!
4.2 140 0.9 2.0 … 4.0 80

38
IPB120N08S4-03
NEW!
2.5 120 0.5 2.0 … 4.0 167

34
IPB120N08S4-04
NEW!
4.1 120 0.8 2.0 … 4.0 95

34
IPB80N07S4-05
NEW!
5.2 80 1.0 2.0 … 4.0 69

34
IPB80N08S4-06
NEW!
5.5 80 1.0 2.0 … 4.0 70

34
IPI120N08S4-03
NEW!
2.5 120 0.5 2.0 … 4.0 167

59
IPI120N08S4-04
NEW!
4.1 120 0.8 2.0 … 4.0 95

59
IPI80N07S4-05
NEW!
5.2 80 1.0 2.0 … 4.0 69

59
IPI80N08S4-06
NEW!
5.5 80 1.0 2.0 … 4.0 70

59
IPP120N08S4-03
NEW!
2.5 120 0.5 2.0 … 4.0 167

52
IPP120N08S4-04
NEW!
4.1 120 0.8 2.0 … 4.0 95

52
IPP80N07S4-05
NEW!
5.2 80 1.0 2.0 … 4.0 69

52
IPP80N08S4-06
NEW!
5.5 80 1.0 2.0 … 4.0 70

52
OptiMOS™-T2 100V (Trench)
Product Type R
DS(on)
[mΩ]
I
D
[A]
R
thJC
(max)
[K/W]
V
GS(th)
(min-max)
[V]
Q
G
(typ)
[nC]
Package
1)
IPD90N10S4L-06 6.6 90 1.1 1.1 … 2.1 75

32
IPD90N10S4-06
NEW!
6.7 90 1.1 2.0 … 3.5 52

32
IPD60N10S4L-12 12.0 60 1.6 1.1 … 2.1 38

32
IPD60N10S4-12
NEW!
12.2 60 1.6 2.0 … 3.5 26

32
IPB180N10S4-02 2.5 180 0.5 2.0 … 3.5 156

38
IPB180N10S4-03
NEW!
3.3 180 0.6 2.0 … 3.5 108

38
IPB120N10S4-03
NEW!
3.5 120 0.6 2.0 … 3.5 108

34
IPB120N10S4-05
NEW!
5.0 120 0.8 2.0 … 3.5 70

34
IPI120N10S4-03
NEW!
3.5 120 0.6 2.0 … 3.5 108

59
IPI120N10S4-05
NEW!
5.0 120 0.8 2.0 … 3.5 70

59
IPP120N10S4-03
NEW!
3.5 120 0.6 2.0 … 3.5 108

52
IPP120N10S4-05
NEW!
5.0 120 0.8 2.0 … 3.5 70

52
