For a comprehensive and reliable portfolio of products
for automotive and other applications, look no further than
the product range from Infineon. We have used our 40
years of experience of developing and producing products
to meet the demands of the automotive market, and our
innovative technologies to design and produce a large
number of power products that meet all requirements of
the automotive industry and also the transportation,
lighting and motor-drive industries.
Our commitment to quality is demonstrated through
our focus on Automotive Excellence, the most rigorous
zero defect program in the industry.
This Selection Guide provides an overview of our ICs
and their packages, which are automotive qualified and
available for your current and future electronic system
designs.
The ultimate power to control your applications including
automotive, transportation, industrial, lighting and motor control.
Symbols
I
D
DC Drain Current
I
GS(TH)
Gate Source Threshold Current
I
IS
Current Sense Output Current
I
L(lim)
Load Current Limit
I
L(NOM)
Load Current (T
a
= 85°C, specified PCB)
I
L(sat)
Saturation Load Current
I
q
Quiescent Current
I
Q
Output Current
Q
G
Total Gate Charge
R
IS
Current Sense Resistor
R
DS(on)
Typical Drain Source Resistance in ON-State @ 25°C
(multiply by 2 for Max @ 150°C)
R
DS(on)
path Typical Drain Source Resistance in ON-State @ 25°C
of both High-Side and Low-Side
R
thJC
Thermal Resistance Junction to Case
V
CE
Collector Emitter Voltage
V
CE(sat)
Saturation Collector Emitter Voltage
V
DS
Drain Source Voltage
V
DS(AZ)
Drain Source Voltage (Active Zener)
V
GS(th)
Gate Threshold Voltage
V
Q
Output Voltage
V
S
Supply Voltage
V
S(AZ)
Supply Voltage (Active Zener)
V
S(op.)
Operation Supply Voltage
Inverse Normal V
S
Polarity and Inverse Load Current
PWM Pulse Width Modulation
Reverse Reverse V
S
Polarity and Reverse Load Current
