OptiMOS™-T2 60V (Trench)
Product Type R
DS(on)
[mΩ]
I
D
[A]
R
thJC
(max)
[K/W]
V
GS(th)
(min-max)
[V]
Q
G
(typ)
[nC]
Package
1)
IPD100N06S4-03 3.5 100 1.0 2.0 … 4.0 99.0

32
IPD90N06S4L-03 3.5 90 1.0 1.2 … 2.0 133.0

32
IPD90N06S4-04 3.8 90 1.0 2.0 … 4.0 99.0

32
IPD90N06S4L-05 4.6 90 1.4 1.2 … 2.0 83.0

32
IPD90N06S4-05 5.1 90 1.4 2.0 … 4.0 62.0

32
IPD90N06S4L-06 6.3 90 1.9 1.2 … 2.0 58.0

32
IPD90N06S4-07 6.9 90 1.9 2.0 … 4.0 43.0

32
IPD50N06S4L-08 7.8 50 2.1 1.2 … 2.0 49.0

32
IPD50N06S4-09 9.0 50 2.1 2.0 … 4.0 36.0

32
IPD50N06S4L-12 12.0 50 3.0 1.2 … 2.0 30.0

32
IPD30N06S4L-23 23.0 30 4.2 1.2 … 2.0 16.1

32
IPD25N06S4L-30 30.0 25 5.1 1.2 … 2.0 12.5

32
IPB180N06S4-H1 1.7 180 0.6 2.0 … 4.0 208

38
IPB120N06S4-H1 2.0 120 0.6 2.0 … 4.0 208

34
IPB120N06S4-02 2.4 120 0.8 2.0 … 4.0 150

34
IPB120N06S4-03 2.8 120 0.9 2.0 … 4.0 125

34
IPB90N06S4L-04 3.4 90 1.0 1.2 … 2.0 133

34
IPB90N06S4-04 3.7 90 1.0 2.0 … 4.0 99

34
IPB80N06S4L-05 4.8 80 1.4 1.2 … 2.0 83

34
IPB80N06S4-05 5.4 80 1.4 2.0 … 4.0 62

34
IPB80N06S4-07 5.4 80 1.4 2.0 … 4.0 62

34
IPB80N06S4L-07 6.4 80 1.9 1.2 … 2.0 58

34
IPB45N06S4L-08 7.9 45 2.1 1.2 … 2.0 49

34
IPB45N06S4-09 9.1 45 2.1 2.0 … 4.0 36

34
IPI120N06S4-H1 2.4 120 0.6 2.0 … 4.0 208

59
IPI120N06S4-02 2.8 120 0.8 2.0 … 4.0 150

59
IPI120N06S4-03 3.2 120 0.9 2.0 … 4.0 125

59
IPI90N06S4L-04 3.4 90 1.0 1.2 … 2.0 133

59
IPI90N06S4-04 4.0 90 1.0 2.0 … 4.0 99

59
IPI80N06S4L-05 4.8 80 1.4 1.2 … 2.0 83

59
IPI80N06S4-05 5.4 80 1.4 2.0 … 4.0 62

59
IPI80N06S4L-07 6.4 80 1.9 1.2 … 2.0 58

59
IPI80N06S4-07 7.1 80 1.9 2.0 … 4.0 43

59
IPI45N06S4L-08 8.2 45 2.1 1.2 … 2.0 49

59
IPI45N06S4-09 9.1 45 2.1 2.0 … 4.0 36

59
IPP120N06S4-H1 2.4 120 0.6 2.0 … 4.0 208

52
IPP120N06S4-02 2.8 120 0.8 2.0 … 4.0 150

52
IPP120N06S4-03 3.2 120 0.9 2.0 … 4.0 125

52
IPP90N06S4L-04 3.4 90 1.0 1.2 … 2.0 133

52
IPP90N06S4-04 3.7 90 1.0 2.0 … 4.0 99

52
IPP80N06S4L-05 4.8 80 1.4 1.2 … 2.0 83

52
IPP80N06S4-05 5.4 80 1.4 2.0 … 4.0 62

52
IPP80N06S4L-07 6.4 80 1.9 1.2 … 2.0 58

52
IPP80N06S4-07 7.1 80 1.9 2.0 … 4.0 43

52
IPP45N06S4L-08 8.2 45 2.1 1.2 … 2.0 49

52
IPP45N06S4-09 9.1 45 2.1 2.0 … 4.0 36

52
www.infineon.com/automotivemosfet
1) See packages on page 112
