OptiMOS™-T2 30V (Trench)
Product Type R
DS(on)
[mΩ]
I
D
[A]
R
thJC
(max)
[K/W]
V
GS(th)
(min-max)
[V]
Q
G
(typ)
[nC]
Package
1)
IPD90N03S4L-02 2.2 90 1.1 1.0 ... 2.2 110

32
IPD90N03S4L-03 3.3 90 1.6 1.0 ... 2.2 60

32
IPD70N03S4L-04 4.3 70 2.2 1.0 ... 2.2 37

32
IPD50N03S4L-06 5.5 50 2.7 1.0 ... 2.2 24

32
IPD40N03S4L-08 8.0 40 3.6 1.0 ... 2.2 15

32
IPD30N03S4L-09 9.0 30 3.6 1.0 ... 2.2 15

32
IPD30N03S4L-14 13.6 30 4.9 1.0 ... 2.2 11

32
IPB240N03S4L-R9
2)
NEW!
0.9 240 0.7 1.0 ... 2.2 230

38
IPB240N03S4L-R8
2)
NEW!
0.8 240 0.5 1.0 ... 2.2 290

38
IPB180N03S4L-H0 1.0 180 0.6 1.0 ... 2.2 230

38
IPB180N03S4L-01 1.1 180 0.8 1.0 ... 2.2 187

38
IPB120N03S4L-03
2)
NEW!
3.0 120 1.9 1.0 ... 2.2 55

34
IPB80N03S4L-02 2.4 80 1.1 1.0 ... 2.2 110

34
IPB80N03S4L-03 3.4 80 1.6 1.0 ... 2.2 60

34
IPB22N03S4L-15 14.6 22 4.9 1.0 ... 2.2 11

34
IPI80N03S4L-03 2.7 80 1.1 1.0 ... 2.2 110

59
IPI80N03S4L-04 3.6 80 1.6 1.0 ... 2.2 60

59
IPI22N03S4L-15 14.9 22 4.9 1.0 ... 2.2 11

59
IPP80N03S4L-03 2.7 80 1.1 1.0 ... 2.2 110

52
IPP80N03S4L-04 3.7 80 1.6 1.0 ... 2.2 60

52
IPP22N03S4L-15 14.9 22 4.9 1.0 ... 2.2 11

52
OptiMOS™-T2 40V (Trench)
Product Type R
DS(on)
[mΩ]
I
D
[A]
R
thJC
(max)
[K/W]
V
GS(th)
(min-max)
[V]
Q
G
(typ)
[nC]
Package
1)
IPLU300N04S4-R8
NEW!
0.8 300 0.4 2.0 … 4.0 221

15
IPLU300N04S4-1R1
3)
NEW!
1.2 300 0.5 2.0 … 4.0 116

15
IPLU300N04S4-1R7
3)
NEW!
1.7 300 0.8 2.0 … 4.0 76

15
IPD100N04S4-02 2.0 100 1.0 2.0 … 4.0 91

32
IPD90N04S4-02 2.4 90 1.0 2.0 … 4.0 91

32
IPD90N04S4-03 3.2 90 1.6 2.0 … 4.0 51

32
IPD90N04S4L-04 3.8 90 2.1 1.2 … 2.0 46

32
IPD90N04S4-04 4.1 90 2.1 2.0 … 4.0 33

32
IPD90N04S4-05 5.2 90 2.3 2.0 … 4.0 33

32
IPD75N04S4-06 5.9 75 2.6 2.0 … 4.0 24.5

32
IPD50N04S4L-08 7.3 50 3.3 1.2 … 2.0 23

32
IPD50N04S4-08 7.9 50 3.3 2.0 … 4.0 17.2

32
IPD50N04S4-10 9.3 50 3.7 2.0 … 4.0 14

32
IPB240N04S4-R9
2)
NEW!
0.9 240 0.5 2.0 … 4.0 220

38
IPB240N04S4-1R0
2)
NEW!
1.0 240 0.7 2.0 … 4.0 170

38
IPB180N04S4L-H0
NEW!
1.0 180 0.6 1.2 … 2.2 239

38
IPB180N04S4-00 1.0 180 0.5 2.0 … 4.0 220

38
IPB180N04S4-H0 1.1 180 0.6 2.0 … 4.0 173

38
www.infineon.com/automotivemosfet
1) See packages on page 112
2) Coming Q4/2014
3) Coming Q2/2015
