15
1) See packages on page 112
Product Type R
DS(on)
[mΩ]
I
D
[A]
R
thJC
(max)
[K/W]
V
GS(th)
(min-max)
[V]
Q
G
(typ)
[nC]
Package
1)
IPB80N06S2L-09 8.2 80 0.8 1.2 … 2.0 82
34
IPB80N06S2-09 8.8 80 0.8 2.1 … 4.0 60
34
IPB80N06S2L-11 10.7 80 0.95 1.2 … 2.0 62
34
IPB77N06S2-12 11.7 77 0.95 2.1 … 4.0 45
34
IPI80N06S2L-05 4.8 80 0.5 1.2 … 2.0 170
59
IPI80N06S2-07 6.6 80 0.6 2.1 … 4.0 86
59
IPI80N06S2-08 8.0 80 0.7 2.1 … 4.0 72
59
IPI80N06S2L-11 11.0 80 0.95 1.2 … 2.0 62
59
BSP603S2L 33.0 5.2 20.0 1.2 … 2.0 31
23
IPP100N06S2L-05 4.7 100 0.5 1.2 … 2.0 170
52
IPP80N06S2L-05 4.8 80 0.5 1.2 … 2.0 170
52
IPP100N06S2-05 5.0 100 0.5 2.1 … 4.0 130
52
IPP80N06S2L-H5 5.0 80 0.5 1.2 … 2.0 145
52
IPP80N06S2-05 5.1 80 0.5 2.1 … 4.0 130
52
IPP80N06S2-H5 5.5 80 0.5 2.1 … 4.0 116
52
IPP80N06S2L-06 6.3 80 0.6 1.2 … 2.0 114
52
IPP80N06S2-07 6.6 80 0.6 2.1 … 4.0 86
52
IPP80N06S2L-07 7.0 80 0.7 1.2 … 2.0 95
52
IPP80N06S2-08 8.0 80 0.7 2.1 … 4.0 72
52
IPP80N06S2L-09 8.5 80 0.8 1.2 … 2.0 82
52
IPP80N06S2-09 9.1 80 0.8 2.1 … 4.0 60
52
IPP80N06S2L-11 11.0 80 0.95 1.2 … 2.0 62
52
IPP77N06S2-12 12.0 77 0.95 2.1 … 4.0 45
52
OptiMOS™ 75V (Planar)
Product Type R
DS(on)
[mΩ]
I
D
[A]
R
thJC
(max)
[K/W]
V
GS(th)
(min-max)
[V]
Q
G
(typ)
[nC]
Package
1)
IPD30N08S2L-21 20.5 30 1.1 2.1 … 4.0 43
32
IPD30N08S2-22 21.5 30 1.1 2.1 … 4.0 44
32
IPD22N08S2L-50 50.0 22 2.0 1.2 … 2.0 21
32
IPB100N08S2L-07 6.5 100 0.5 1.2 … 2.0 185
34
IPB100N08S2-07 6.8 100 0.5 2.1 … 4.0 153
34
IPB80N08S2L-07 6.8 80 0.5 1.2 … 2.0 186
34
IPB80N08S2-07 7.1 80 0.5 2.1 … 4.0 182
34
IPI100N08S2-07 7.1 100 0.5 2.1 … 4.0 144
59
IPI80N08S2-07 7.4 80 0.5 2.1 … 4.0 144
59
IPP100N08S2L-07 6.8 100 0.5 1.2 … 2.0 182
52
IPP100N08S2-07 7.1 100 0.5 2.1 … 4.0 144
59
IPP80N08S2L-07 7.1 80 0.5 1.2 … 2.0 183
52
IPP80N08S2-07 7.4 80 0.5 2.1 … 4.0 144
59
www.infineon.com/automotivemosfet
