H-Bridges for Powertrain Applications
The Infineon H-Bridge portfolio addresses a broad range
of DC brush motor applications. Originally designed
and optimized for Electronic Throttle Control (ETC), the
H-Bridges can also be used for applications like Exhaust
Gas Recirculation (EGR) valve control, idle control, swirl
and tumble flaps, variable intake manifold, turbo charger
waste gate, variable turbo geometry or industrial DC brush
motor applications.
Product Type R
DS(on)
HS
[mΩ]
R
DS(on)
LS
[mΩ]
I
LIM
min.
[A]
I
Q
max.
[mA]
V
S(OP)
[V]
Diagnostic IF V
DD
Mon. Package
1)
TLE5205-2G 220 220 6.0 10 6.0 … 40.0 Status Flag

39
TLE5206-2 220 220 6.0 10 6.0 … 40.0 Status Flag

55
TLE5206-2S 220 220 6.0 10 6.0 … 40.0 Status Flag

57
TLE6209R 140 130 3.4 … 5.95 0.05 5.2 … 40.0 SPI

8
TLE7209-2R 150 150 5.5 20 5.0 … 28.0 SPI & Status Flag

8
TLE7209-3R 150 150 5.5 20 5.0 … 28.0 SPI & Status Flag

8
TLE8209-2SA 115 125 1.0 … 7.7 0.02 4.5 … 28.0 SPI & Status Flag
l

8
TLE8209-2E 115 125 1.0 … 7.7 0.02 4.5 … 28.0 SPI & Status Flag
l

7
TLE8209-4SA 115 125 1.0 … 9.0 0.02 4.5 … 28.0 SPI & Status Flag
l

8
TLE9201SG 100 100 5.0 0.03 5.0 … 28.0 SPI & Status Flag

3
Flex Multichannel Low-Side Switches (Powertrain & Safety)
Multi channel low-side switches are designed for multi
purpose loads (solenoids, relays and resistive loads). The
so-called Flex products serve in a flexible way the engine
requirements with a dierent number of low-side drivers.
Please refer to page 40 for the product table.
1) See packages on page 112
