Ultimate Power – Perfect Control Vehicle Safety, Body and Powertrain Applications www.infineon.
For a comprehensive and reliable portfolio of products for automotive and other applications, look no further than the product range from Infineon. We have used our 40 years of experience of developing and producing products to meet the demands of the automotive market, and our innovative technologies to design and produce a large number of power products that meet all requirements of the automotive industry and also the transportation, lighting and motor-drive industries.
Automotive Applications Electric Sunroof Rear Wiper Suspension Airbag Window Lift Power Seat Electric Mirrors Power Door Font Wiper Body Control Module/Gateway Starter Alternator Steering Lighting Throttle Control Headlight Leveling Engine Control Transmission HVAC Hybrid Brake System Automotive Power Components Used in Other Applications Agriculture Transportation/Navigation Lighting Automation/Industrial Toys/Games Electric Tools/Home Appliance/He
Requirements We meet all requirements for cost-effective application solutions Smart Power ICs Power System ICs Smart Multichannel Switches – For Body: SPIDER – For Powertrain and Safety: Flex C DC and Stepper Motor Driver ICs C NovalithIC™/Trilith IC – High-Current Motor Drivers C Driver ICs C Voltage Regulators C CAN/LIN Transceivers C DC/DC Converters C C C Smart Power System Integration – ABS/Airbag – Powertrain – Body Infineon® Embedded Power ICs Single Package and Single Die C Smart Power and
Content Typical Body Applications 6 Infineon® Auto LED Drivers 56 Typical Powertrain Applications 8 Motor Drivers 61 Integrated Low-Current Motor Drivers 62 Integrated High-Current Motor Drivers 66 Gate Driver ICs for External MOSFETs 69 Typical Safety Applications 10 Automotive MOSFETs 12 Infineon® Embedded Power ICs 72 Small Signal MOSFETs 24 Power Supply 80 Power MOSFETs 28 Automotive Transceivers 90 TEMPFET™: Temperature Protected Switches 30 System Basis Chips (SBCs) 94
Body Applications Body Control Module Highbeam 65W Optional Fog 2x 55W Park Indicator Lowbeam Highbeam 55W 65W 10W 27W PROFET™ BTS5016-1/2 SPOC™ FL BTS5482SF SPOC™+ BTS54220-LBx Headlight Assembly M Headlight Assembly PROFET™ BTS5012-1 BTS5016-1/2 PROFET™ BTS5045-2 BTS5120-2 Single or Dual High-Side Driver LEDs Multi-Channel High-Side Driver Relays Body Control Module LIN Bus CAN Bus 1x … 4x LIN Bus CAN Bus +12V from Battery CAN TRX TLE7250G TLE6251-3G TLE6251D XC22xx Family (optional) LI
Decentralized Front Light Module Curve Light +12V from Battery/ +12V Switched 8-bit Microcontroller XC8xx Stepper Motor Driver Motor Driver / Beam Control Supply Decentralized Light Control Module Position Sensor TLE4964 Light Leveling Stepper Motor Driver System Basis Chip TLE9260 TLE9261 CAN Bus M Position Sensor TLE4964 Power LED Driver TLD5095EL TLD5097EL TLD5098EL 16/32-bit Microcontroller XC22xx Power LED Driver TLD5095EL TLD5097EL TLD5098EL LED Driver Communication Optional: LIN Bus
Powertrain Applications Gasoline Multi-Port Injection – Discrete Solution Engine Management Safety System Supply Battery (KL30) Key (KL15) StByLDO µC-LDO Ref-LDO Com-LDO Tracker 1 Tracker 2 Typical Partitioning for up to 6 cyl. MPI w. discrete "Flex" UV/OV/Error-Monitoring Fuel Level TLE4997/98 4x QSPI 50x SAR Swirl/Tumble Flap TLE4997/98 Throttle Position TLE4998S Temperature Sensor(s) 3x DS 32-bit Multicore/Lockstep MCU AURIX™ e.g. TC26xD 2.
Automatic Transmission – Hydraulic Control 9-Speed Automatic Transmission Safety System Supply Battery (KL30) Key (KL15) StByLDO µC-LDO Ref-LDO Com-LDO Typical Partitioning for Constant Current Control Tracker 1 Tracker 2 UV/OV/Error-Monitoring Hill Hold TLE4998 10x DS 5V/0.2A 3.3V or 5V/0.6A 3.3V or 5V/10mA 5V/0.15A 84x SAR Output Shaft Speed TLE4951/54 Low-Side Driver 6x QSPI HSM 32-bit Multicore/Lockstep MCU AURIX™ e.g.
Safety Applications Airbag System Reversible Belt Pretensioners ECU CAN-Bus or LIN-Bus CAN LIN KP201 Pedestrian Protection Sensors Door Pressure Sensor KP108 KP200 ADXL15X ADXL15X Door Satellite Sensor Interface TLE7729 Sensor SPI Bus 32-bit MCU AURIX™ Firing SPI Bus LIN Transceiver TLE7259-3GE TLE7257SJ TLE7258SJ CAN Transceiver TLE6251D TLE7250GVIO Pressure Sensor KP108 Squib Driver 8-Channel TLE8758 Squib Driver 4-Channel TLE8754 Squib Squib Squib Squib Squib Squib Squib Squib Squi
Electric Power Steering (EPS) +12V from Battery Safety System Supply StBy- µC-LDO Ref-LDO Com-LDO Tracker 1 LDO Tracker 2 UV/OV/Error-Monitoring Window/Q&AWatchdog VSens Torque Sensor VTx WD Electric Power Steering ECU 3-Phase Driver IC TLE7183 TLE7185 TLE7189 TLE9180 Family M Rotor Position iGMR Sensor TLE5012BD TLE5309D FD Current Sense (Shunt Substitute) TLE4997/98 CAN Transceiver TLE7250GVIO TLE6251D FlexRay Transceiver TLE9221SX TLE9222PX1) 1) In development VMCU 32-bit Multicore Lockstep
Automotive MOSFETs Infineon OptiMOS™ – Benchmark for Automotive MOSFETs OptiMOS™ Products are Best in Class OptiMOS™ superior performance is based on Infineon’s leading MOSFET technology combined with the unsurpassed quality of robust package: Best in class RDS(on) performance for increased system efficiency Lowest switching and conduction power losses for increased thermal system reliability Robust green package for easy process handling OptiMOS™ Robust Green Package OptiMOS™ robust package is th
MOSFETs TEMPFET ™ HITFET ™ Smart Multichannel Switches PROFET ™ Company: I for Green Products S for Non-Green Products Device: P for Power-MOSFET Package Type: G for Dual SuperSO8 P for TO220 B for D2PAK (TO263) D for DPAK (TO252) I for I2PAK (TO262) Continuous Drain Current/ID(max.
Automotive N-Channel MOSFETs OptiMOS™ 30V (Planar) Product Type IPD50N03S2L-06 IPD30N03S2L-07 IPD50N03S2-07 IPD30N03S2L-10 IPD30N03S2L-20 RDS(on) [mΩ] 6.4 6.7 7.3 10.0 20.0 ID [A] 50 30 50 30 30 RthJC (max) [K/W] 1.1 1.1 1.1 1.5 2.5 VGS(th) (min-max) [V] 1.2 … 2.0 1.2 … 2.0 2.1 … 4.0 1.2 … 2.0 1.2 … 2.0 QG (typ) [nC] 50 51 52 31 14 Package1) ID [A] 160 160 100 100 80 80 80 80 80 100 80 100 80 80 RthJC (max) [K/W] 0.5 0.5 0.5 0.5 0.5 0.5 0.5 0.5 0.5 0.5 0.5 0.5 0.5 0.5 VGS(th) (min-max) [V] 1.2 … 2.
MOSFETs 80 0.8 2.1 … 4.0 60 IPB80N06S2L-11 10.7 80 0.95 1.2 … 2.0 62 IPB77N06S2-12 11.7 77 0.95 2.1 … 4.0 45 IPI80N06S2L-05 4.8 80 0.5 1.2 … 2.0 170 IPI80N06S2-07 6.6 80 0.6 2.1 … 4.0 86 IPI80N06S2-08 8.0 80 0.7 2.1 … 4.0 72 IPI80N06S2L-11 11.0 80 0.95 1.2 … 2.0 62 BSP603S2L 33.0 5.2 20.0 1.2 … 2.0 31 IPP100N06S2L-05 4.7 100 0.5 1.2 … 2.0 170 IPP80N06S2L-05 4.8 80 0.5 1.2 … 2.0 170 IPP100N06S2-05 5.0 100 0.5 2.1 … 4.0 130 IPP80N06S2L-H5 5.
Automotive N-Channel MOSFETs OptiMOS™-T 100V (Trench) Product Type RDS(on) [mΩ] ID [A] IPB100N10S3-052) 4.8 100 IPB70N10S3-12 11.3 70 IPB70N10S3L-12 11.8 70 IPB50N10S3L-16 15.4 70 IPB35N10S3L-26 26.3 IPD70N10S3-122) VGS(th) (min-max) [V] QG (typ) [nC] Package1) 0.5 2.0 … 4.0 135 1.2 2.0 … 4.0 51 1.2 1.2 … 2.4 60 1.5 1.2 … 2.4 49 35 2.1 1.2 … 2.4 30 11.1 70 1.2 2.0 … 4.0 51 IPD70N10S3L-122) 11.5 70 1.2 1.2 … 2.4 60 IPD50N10S3L-16 15.0 50 1.5 1.2 … 2.
MOSFETs VGS(th) (min-max) [V] QG (typ) [nC] Package1) IPD90N03S4L-02 2.2 90 1.1 1.0 ... 2.2 110 IPD90N03S4L-03 3.3 90 1.6 1.0 ... 2.2 60 IPD70N03S4L-04 4.3 70 2.2 1.0 ... 2.2 37 IPD50N03S4L-06 5.5 50 2.7 1.0 ... 2.2 24 IPD40N03S4L-08 8.0 40 3.6 1.0 ... 2.2 15 IPD30N03S4L-09 9.0 30 3.6 1.0 ... 2.2 15 IPD30N03S4L-14 13.6 30 4.9 1.0 ... 2.2 11 0.9 0.8 1.0 240 240 180 0.7 0.5 0.6 1.0 ... 2.2 1.0 ... 2.2 1.0 ... 2.2 230 290 230 1.1 180 0.8 1.0 ... 2.2 187 3.
Automotive N-Channel MOSFETs OptiMOS™-T2 40V (Trench) (cont’d) Product Type IPB180N04S4-01 RDS(on) [mΩ] ID [A] RthJC (max) [K/W] VGS(th) (min-max) [V] QG (typ) [nC] Package1) 38 38 34 38 34 34 34 34 34 34 34 34 34 34 59 59 59 59 59 59 59 59 59 52 52 52 52 52 52 52 52 52 43 43 43 43 1.3 180 0.8 2.0 … 4.0 135 IPB180N04S4L-01 IPB160N04S4-H1 NEW! 1.2 1.6 180 160 0.8 0.9 1.2 … 2.0 2.0 … 4.
MOSFETs 100 90 90 90 90 90 90 50 50 50 30 25 180 120 120 120 90 90 80 80 80 80 45 45 120 120 120 90 90 80 80 80 80 45 45 120 120 120 90 90 80 80 80 80 45 45 1.0 1.0 1.0 1.4 1.4 1.9 1.9 2.1 2.1 3.0 4.2 5.1 0.6 0.6 0.8 0.9 1.0 1.0 1.4 1.4 1.4 1.9 2.1 2.1 0.6 0.8 0.9 1.0 1.0 1.4 1.4 1.9 1.9 2.1 2.1 0.6 0.8 0.9 1.0 1.0 1.4 1.4 1.9 1.9 2.1 2.1 2.0 … 4.0 1.2 … 2.0 2.0 … 4.0 1.2 … 2.0 2.0 … 4.0 1.2 … 2.0 2.0 … 4.0 1.2 … 2.0 2.0 … 4.0 1.2 … 2.0 1.2 … 2.0 1.2 … 2.0 2.0 … 4.0 2.0 … 4.0 2.0 … 4.0 2.0 … 4.0 1.2 … 2.
Automotive N-Channel MOSFETs OptiMOS™-T2 80V (Trench) Product Type IPD90N08S4-05 IPD50N08S4-13 IPB180N08S4-02 IPB160N08S4-03 IPB140N08S4-04 IPB120N08S4-03 IPB120N08S4-04 IPB80N07S4-05 IPB80N08S4-06 IPI120N08S4-03 IPI120N08S4-04 IPI80N07S4-05 IPI80N08S4-06 IPP120N08S4-03 IPP120N08S4-04 IPP80N07S4-05 IPP80N08S4-06 NEW! NEW! NEW! NEW! NEW! NEW! NEW! NEW! NEW! NEW! NEW! NEW! NEW! NEW! NEW! NEW! NEW! RDS(on) [mΩ] ID [A] RthJC (max) [K/W] VGS(th) (min-max) [V] QG (typ) [nC] Package1) 5.3 13.2 2.2 3.2 4.
MOSFETs 4.5 4.5 6.8 10.5 4.1 4.7 6.9 10.8 4.4 7.2 11.1 4.4 7.2 11.1 -90 -90 -80 -50 -80 -80 -80 -45 -80 -80 -45 -80 -80 -45 1.1 1.1 1.7 2.6 1.1 1.1 1.7 2.6 1.1 1.7 2.6 1.1 1.7 2.6 -2.0 … -1.0 -4.0 … -2.0 -2.0 … -1.0 -2.0 … -1.0 -2.0 … -1.0 -4.0 … -2.0 -2.0 … -1.0 -2.0 … -1.0 -2.0 … -1.0 -2.0 … -1.0 -2.0 … -1.0 -2.0 … -1.0 -2.0 … -1.0 -2.0 … -1.
Automotive P-Channel MOSFETs OptiMOS™-P2 40V P-Channel (Trench) (cont’d) Product Type IPI120P04P4L-03 IPI120P04P4-04 IPI80P04P4L-04 IPI80P04P4-05 IPI80P04P4L-06 IPI80P04P4-07 IPI70P04P4L-08 IPI70P04P4-09 RDS(on) [mΩ] ID [A] RthJC (max) [K/W] VGS(th) (min-max) [V] QG (typ) [nC] Package1) 3.4 3.9 4.7 5.2 6.7 7.6 8.2 9.4 -120 -120 -80 -80 -80 -80 -70 -70 1.1 1.1 1.2 1.2 1.7 1.7 2.0 2.0 -2.2 … -1.7 -4.0 … -2.0 -2.2 … -1.7 -4.0 … -2.0 -2.2 … -1.7 -4.0 … -2.0 -2.2 … -1.7 -4.0 … -2.
NEW! NEW! MOSFETs VGS(th) (min-max) [V] QG (typ) [nC] Package1) 2 x 15.5 2 x 15.5 2 x 11.1 2 x 11.1 2 x 13.7 2 x 13.7 2 x 26.0 2 x 26.0 20 20 20 20 20 20 20 20 3.0 3.0 2.3 2.3 3.0 3.0 4.5 4.5 2.0 … 4.0 2.0 … 4.0 1.2 … 2.2 1.2 … 2.2 1.2 … 2.2 1.2 … 2.2 1.2 … 2.2 1.2 … 2.
Small Signal MOSFETs Infineon offers a full range of Small Signal MOSFETs qualified according AEC Q101. The portfolio includes: Configuration: single, dual, complementary (n+p pairs) Polarity: N-Channel enhancement, N-Channel Additional features: the products with names ending with depletion and P-Channel MOSFETs Voltage classes: -250 ... 800V VGS rating: 10V (Normal Level), 4.5V (Logic Level), 2.5V (Super Logic Level), 1.
100V 200V 6,000 6,000 6,000 14,000 0.35 0.35 0.26 0.11 0.8 … 1.8 0.6 … 1.4 0.8 … 1.8 0.8 … 1.8 4.3 4.5 3.7 2.1 SIPMOS™ SIPMOS™ SIPMOS™ SIPMOS™ 240V 1) See packages on page 112 www.infineon.com/smallsignalmosfets www.infineon.com/complementary www.infineon.com/pchannel www.infineon.
Small Signal MOSFETs N-Channel MOSFETs (cont’d) Voltage 400V 500V 600V 800V Product Type RDS(on) (max) [mΩ] ID [A] VGS(th) (min-max) [V] QG (typ) [nC] Technology Package1) BSP298 BSP324 BSP299 BSP125 BSS225 BSS127 BSP300 3,000 25,000 4,000 45,000 45,000 500,000 20 0.5 0.17 0.4 0.12 0.09 0.023 0.19 2.1 … 4.0 1.3 … 2.3 2.1 … 4.0 1.3 … 2.3 1.3 … 2.3 1.4 … 2.6 2.1 … 4.0 – 4.5 – 4.4 3.9 1.
MOSFETs QG (typ) Technology Package1) [nC] -12.4 -9.0 -5.1 -3.0 -11.6 -4.3 -4.9 -3.
Power MOSFETs 600V CoolMOS™ CPA and 650V CoolMOS™ CFDA After launching the first series of high voltage automotive MOSFET the 600V CoolMOS™ CPA series, Infineon has launches its second generation of market leading Automotive qualified high voltage MOSFET the 650V CoolMOS™ CFDA series.
MOSFETs PFC Stage DC/DC Stage Smart Multichannel Switches Bridge Rectifier TEMPFET ™ HITFET ™ Example for Automotive Topology using CoolMOS™ CFDA N:1 VBattery CoolMOS™ CPA PROFET ™ VAC 4x CoolMOS™ CFDA RDS(on) @ TJ = 25°C VGS = 10V [mΩ] ID (max) @ TJ = 25°C [A] IDpuls (max) 105 199 299 105 45 75 105 105 31 16 11 31 60 39 31 31 IPB60R099CPA IPB60R199CPA IPB60R299CPA IPP60R099CPA IPW60R045CPA IPW60R075CPA IPW60R099CPA IPI60R099CPA QG (typ) RthJC (max) [A] VGS(th) (min-max) [V] Package1)
TEMPFET™: Temperature Protected Switches TEMPFET™ provides the first level of temperature and current protection via its temperature sensor. The temperature sensor is available on external pins and enables direct gate access and flexible temperature response control.
MOSFETs Infineon has recently expanded its HITFET™ portfolio with the new product BTF3050TE.
HITFET™: Low-Side Protected Switches Selection Tree HITFET™ Protection Function Overtemperature Overcurrent Overvoltage ESD Supply Voltage Optimized for 12V Overtemperature Behavior Auto Restart Latch Number of Channels 1 SCT595 12V and 24V Number of Channels Number of Channels 1 1 2 SOT223 DSO-8 DPAK DSO-8 SOT223 DPAK D2PAK DPAK BTS3160D BTS3256D 10mΩ, 7.8A 10mΩ, 7.5A BTS149 18mΩ, 6.4A BTS3028SDL 28mΩ, 4.0A BTS3142D BTS142D 30mΩ, 4.6A 30mΩ, 4.6A BTS141 28mΩ, 5.
MOSFETs TEMPFET ™ HITFET ™ PWM [kHz] Diagnostic Package1) BTS3160D 10 1 40 7.8 70.0 1 digital BTS3256D 10 1 40 7.5 42.0 10 digital BTS3142D 28 1 42 4.6 30.0 1 through input pin BTS142D 28 1 42 4.6 30.0 1 through input pin BTS3134N 50 1 42 3.0 18.0 1 through input pin BTS3134D 50 1 42 3.5 18.0 1 through input pin BSP78 50 1 42 3.0 18.0 1 through input pin BTF3050TE 50 1 40 3.0 30 (8) 10 through SRP pin BTS134D 50 1 42 3.5 18.
Smart Multichannel Switches for Body: SPIDER – SPI Driver for Enhanced Relay Control SPIDER stands for SPI Driver for Enhanced Relay control. SPIDER products are the smallest relay drivers in the market with innovative features and packages. configurations (SPIDER Low-Side), as well as configurable 8-channel high-/low-side configurations (SPIDER High-/ Low-Side).
MOSFETs TEMPFET ™ HITFET ™ Smart Multichannel Switches Selection Tree SPIDER Smart Multichannel Switches (Body) Number of Channels Number of Channels 8 4 8 TLE7230R TLE7240SL TLE7243SL TLE7244SL TLE7231G TLE7233G Standard Limp Home Limp Home + Cranking TLE7237SL TLE7234SE TLE7234EM TLE7238SL TLE7235SE TLE7235EM TLE7239SL TLE7236SE TLE7236EM SPOC™ – SPI Power Controller Number of Channels PROFET ™ High-Side/Low-Side LED Drivers Low-Side IN1 IN2 IN3 IN4 LHI Input Mux and Control CS SCLK
Smart Multichannel Switches for Body: SPIDER – SPI Driver for Enhanced Relay Control SPIDER Product Table Product Type SPIDER LS SPIDER HS/LS High-Side Small High-Side Low-Side Configurable TLE7230R – – 8 – TLE7240SL – – 8 – TLE7243SL – – 8 – TLE7244SL – – 8 – TLE7231G – – 4 – TLE7233G – – 4 – TLE7237SL 2 2 2 2 TLE7238SL 2 2 2 2 TLE7239SL 2 2 2 2 TLE7234SE 2 2 2 2 TLE7235SE 2 2 2 2 TLE7236SE 2 2 2 2 TLE7234EM 2 2 2 2 TLE7235EM 2 2 2
MOSFETs TEMPFET ™ HITFET ™ Smart Multichannel Switches PROFET ™ SPOC™ – SPI Power Controller IL(nom) [mA] Number of Direct Inputs Package 1) 0.8 – 48 1.5 – 41 l 500 4 210 4 l 260 4 l 290 4 320 1 390 4 6 x 260; 2 x 120 3 6 x 260; 2 x 120 2 13 29 29 29 4 29 29 29 29 6 6 6 30 30 30 1.2 – 41 0.8 – 41 1.0 – 41 1.0 – 41 6 x 0.9; 2 x 1.6 – 41 6 x 0.9; 2 x 1.6 – 41 l l l 4 41 – 41 6 x 260; 2 x 120 2 6 x 280; 2 x 140 3 6 x 0.
Smart Multichannel Switches for Powertrain and Safety: Flex The Flex Multichannel Low-Side Switches family for powertrain, safety and industrial applications is specially designed to drive a various range of loads from relays, injector valves, oxygen probe heaters and general purpose solenoids, through to unipolar stepper motors. We offer a complete family concept with full scalability from 2 to 18 channels and leading edge technology.
MOSFETs TEMPFET ™ HITFET ™ Block Diagram Flex (TLE8102SG) Proportional Current Sense Reset Temperature Sensor Sleep Mode Hardware Configuration CS SCLK SI CO2 [SO/ST2] Short-Circuit Detection Control Diagnostic and Protective Functions SPI PROFET ™ Input Control OUT1 Open-Load Detection OUT2 Selectable Current Limit Gate Control Current Sense/ Diagnosis Undercurrent Detection LED Drivers CO1 [IS1/IS2/ ST1/FAULT] SPOC™ – SPI Power Controller IN1 IN2 Smart Multichannel Switches VDD Mo
Smart Multichannel Switches for Powertrain and Safety: Flex Product Table Target Loads2) TLE8102SG TLE6220GP TLE8104E TLE6232GP High-Current-Solenoids, O2-Heater Injectors, High-Current-Solenoids, Stepper-Motor Injectors, High-Current-Solenoids, Stepper-Motor High-Current-Relays, Injectors, High-Current-Solenoids Channels Electrical Specification # RDS (max) @ 25°C [mΩ] IL(lim) (max) [A] VCL (typ) [V] 2 2x 0.18 5.0 (9.0) 54 4 4x 0.32 3.0 53 4 4x 0.32 3.0 53 6 4x 2x 0.25 0.45 3.0 1.
MOSFETs TEMPFET ™ HITFET ™ Smart Multichannel Switches PROFET ™ SPOC™ – SPI Power Controller Package1) l 3 l l 8 l l 6 l l 13 l l 13 30 l 12 I-limit Switch-Off 8-bit l l l 4 8-bit l 4 8-bit l 6 16-bit 4 16-bit 4 16-bit l 10 16-bit l 3) 8 16-bit l l l l l 13 13 Glossary Automotive System ICs LVDS + LVTTL l LED Drivers Status Flag Daisy-Chain Motor Drivers 2 Overcurrent Protection MSC Power Supply SPI Automotive Transceivers Interfa
PROFET ™: Smart High-Side Switches The highly integrated PROFET™ family (PROtected FET) incorporates a broad range of smart features, like diagnosis and protection. PROFET™ intelligent power switches consist of DMOS power transistor and CMOS logic circuitry for complete built-in protection. The PROFET™ family offers protection against overload, overvoltage, short-circuit, excessive temperature, ground loss, power supply loss and Electrostatic Discharge (ESD).
MOSFETs Base Chip Voltage Sensor T Overtemperature Smart Multichannel Switches Load Current Sense OUT GND Application Examples Basic Features Lighting High-side switches (0.
PROFET ™: Smart High-Side Switches No Diagnosis Basic Features 12V or 24V capable Single channel Product Type Automotive Grade BTS4140N2) BSP742T BSP452 BTS452T BSP752T BTS4141N BTS4142N BSP762T BTS462T BTS730 BSP772T BTS441T Protection Features Short circuit protection Current limitation Overvoltage protection Overtemperature protection Product Family Classic PROFET™ Classic PROFET™ Classic PROFET™ Classic PROFET™ Classic PROFET™ Classic PROFET™ Classic PROFET™ Classic PROFET™ Classi
MOSFETs TEMPFET ™ HITFET ™ Smart Multichannel Switches 0.9 4.0 1.5 6.5 6.5 2.1 3.0 10.0 14.0 20.0 17.0 65.0 l 23 1 23 33 1 23 23 1 33 6 1 36 [A] l l l l l PROFET ™ 4.9 … 60 5.0 … 34 5.0 … 34 6.0 … 52 6.0 … 52 12.0 … 45 12.0 … 45 5.0 … 34 5.0 … 34 5.9 … 16 5.0 … 34 4.75 … 41 Package1) SPOC™ – SPI Power Controller 1000 @ 0.15A 100 @ 0.5A 500 @ 0.5A 150 @ 1A 125 @ 1A 700 @ 0.7A 160 @ 1A 870 @ 1A 4400 @ 1A n.a. 900 @ 1.
PROFET ™: Smart High-Side Switches Digital Diagnosis Basic Features 12V or 24V capable Single or multi channel Product Type Protection Features Overload protection Loss of battery / GND Short circuit protection Overvoltage protection Product Family RDS(on) (typ) Diagnosis Features Open drain status feedback Overtemperature Open load Current limitation [mΩ] RDS(on) (max.
MOSFETs TEMPFET ™ HITFET ™ Smart Multichannel Switches to battery l l l l l l l l l l l l l l l l Packages1) Open Load in ON-State l l l l l l l l l l l l l l l l l l l l l l l l l l l l l l l l l l l l l l l l l l l l l l l l l l l l l l l l l l Automotive System ICs Automotive Transceivers l 1 1 1 1 6 6 13 1 4 33 4 3 6 6 6 4 6 3 6 33 53 36 36 53 36 PROFET ™ to GND l l Short Circuit Di
PROFET ™: Smart High-Side Switches Current Sense, Current Input Basic Features 12V or 24V capable Single channel Product Type BTS6163D BTS443P BTS5016SDA BTS5014SDA BTS5012SDA BTS6142D BTS6143D BTS6133D BTS50085-1TMA BTS50085-1TMB BTS50080-1TMA BTS50080-1TMB BTS50080-1TMC BTS50080-1TEA BTS50080-1TEB BTS50070-1TMA BTS50070-1TMB BTS50055-1TMA BTS50055-1TMB BTS50055-1TMC BTS550P BTS555 Protection Features Current limitation Overload protection Short circuit shutdown ReverSave™ Loss of G
MOSFETs TEMPFET ™ HITFET ™ Smart Multichannel Switches l l l l l l l l l l l l l l l l l l l l l l l l l l l l l l l l l l l l l l l l l l l l l l l l l l l l l 33 33 33 33 33 33 33 33 39 55 39 56 39 33 33 39 56 39 55 39 51 51 l l l l l l l l l l l l Glossary Automotive System ICs Automotive Transceivers l l l PROFET ™ l SPOC™ – SPI Power Controller Packages1) l Inverse Current Operation Capabi
PROFET ™: Smart High-Side Switches Current Sense, Voltage Input Basic Features 12V or 24V capable Single or multi channel Product Type Automotive Grade BTS5200-4EKA BTT6200-4EMA3) BTT6200-1EJA3) BTS5180-2EKA BTS5120-2EKA BTT6100-2EKA3) BTS5090-2EKA BTS5090-1EJA BTS6110-1SJA BTT6050-1EKA BTT6050-2EKA BTS5045-2EKA BTS5045-1EJA BTS740S2 BTS640S2G BTT6030-2EKA BTT6030-1EKA BTT6020-1EKA BTS5030-2EKA BTS5030-1EJA BTS5020-2EKA BTS5020-1EKA BTS5016-2EKA BTS5016-1EKB BTS5012-1EKB BTS5010-1EKB BTT6010-1EKA4)
MOSFETs TEMPFET ™ HITFET ™ Smart Multichannel Switches PROFET ™ l l l l l l l l l l l l l l l l l l l l l l l l l l l l l l l l l l l l l l l l l l l l l l l l l l l l l l l l l l l l l l l l l l l l l l l l l l l l l l l l l l l l l l l l l l l l l l l l l l l l l l l l l l l l l l l l l l l l l l l l l l l l l l l l l l l Packages1) 5 30 2 5 5 5 5 2 1 5 5 5
SPOC™: SPI Power Controller SPOC™ devices are high-side smart power Multichannel switches providing embedded protection diagnosis and intelligence. They are specially designed for standard exterior lighting in automotive applications, but can be used for further automotive and industrial applications such as heating, motor driving or power distribution. Integration helps reducing the complexity of the lectronics, allowing board space reduction and decreasing the need for external components.
MOSFETs TEMPFET ™ HITFET ™ Smart Multichannel Switches PROFET ™ Block Diagramm (SPOC™+ Example): BTS54220-LBE VS EDO EDD Gate Control & Charge Pump Load Current Sense Load Current Limitation Channel 1 ESD Protection IS LHI CS SCLK Current Sense Multiplexer Temperature Monitor Inverse cur.
MOSFETs TEMPFET ™ HITFET ™ SPI Power Controller (SPOC™) for Advanced Light Control S a b c d e – LB f Infineon PROFET ™ S for Car a Complexity 5 (no PMW) SPOC™ – SPI Power Controller b Channel # 4 = 4 Channels, … c 65W Ch. # LED Drivers d 27W Ch. # e 10W Ch. # Package Denomination Product Table Product Type Channel mix [mΩ] 65W 27W LED mode (27W channels) PWM engine integrated External drive capability Package1) l 11 11 10W SPOC™ FL (Front Light) BTS5482SF 2 x 4.
Infineon® Auto LED Driver Infineon® Auto LED Driver are an enabler of protected and high performing lighting applications in automotive. In particular the constant current regulation secures the stable brightness of the LED over the whole automotive temperature and voltage range. The driver as well as the LED are protected gainst overstress e.g. caused by voltage spikes or overtemperature. Any kind of load conditions are detected by its diagnostic features such as open load or shorted LED.
MOSFETs Infineon® Linear LED Driver TEMPFET ™ HITFET ™ BCR400 series is the most cost effective solution to drive low power LED PROFET ™ VS SPOC™ – SPI Power Controller Ven: BCR320 BCR420 µC XC866 Product Table Product Type Output Current (max) [mA] Adjustable Output Current Supply Voltage (max) [V] 65 65 65 65 65 250 250 150 150 l 40 18 40 18 40 27 27 40 40 BCR401U BCR401W BCR402U BCR402W BCR405U BCR320U BCR321U BCR420U BCR421U l l l l l l l PWM enable l l l l Ptot [mW] Package1) 7
Infineon® Linear LED Driver Linear Current Sources for Low to Medium Power Applications LED drivers designed to supply constant current up to 500mA, which enables constant LED brightness and ensures extended LED lifetime, independently from supply voltage or LED forward voltage class. Block Diagram TLD1211SJ VBat BAS3010A-03W VReg TLE42644 VI 5V VO 10µF GND Microcontroller OUT/ XC866 PWM 1.8kΩ GND 1kΩ N.C. N.C.
Infineon’s Basic LED driver are optimized for the control of low to medium power LEDs in automotive applications. The whole family of linear constant current sources offers footprint compatibility ranging from 1 to 3 output channels and 60–180mA and enables stable and reliable LED brightness by precise current control. MOSFETs Its diagnostics and logic feature set enables improved system reliability by significant component reduction on board level, improved system protection (e.g.
Infineon® Power LED Driver DC/DC Converter & Controller for High Power Applications Increasingly, LED lighting solutions are used in the front area of the car, especially in the Premium segment. LED Frontlight solutions are usually implemented using several discrete LEDs in one chain which leads to a string voltage of up to 60V or using less LEDs with high forward current up to 1.5A. Both implementations are requiring DC/DC solutions either boost, buck or buck-boost architectures are needed.
MOSFETs TEMPFET ™ HITFET ™ Smart Multichannel Switches H-Bridge Driver IC + 4x MOSFET ( TLE...) 3-Phase Driver IC + 6x MOSFET (TLE...) 3-Phase 100A DC Brush 3~ M DC Brush 10A M DC Brush DC Brush M M 0.1A Automotive System ICs 1A LED Drivers SPOC™ – SPI Power Controller PROFET ™ Trilith IC or NovalithIC™ (BTM… BTN…) Monolithic Bridges ( TLE...) Motor Drivers Stepper / Servo Drivers ( TCA… TLE…) right solution for every current range and application requirement.
Integrated Low-Current Motor Drivers The Infineon low-current DC motor bridge family consists of a broad variety of bridges for stepper and DC brush motors including servo motors. They are designed for use in automotive and industrial applications. Typical applications are light leveling, HVAC flap control, and mirror adjustment. The products are offered with protection features as well as diagnosis.
MOSFETs The devices are built using DOPL, Infineon’s robust bipolar technology. +VB DR 1N4001 CS PROFET ™ +VB Smart Multichannel Switches The TLE4205, TLE4206 and TLE4209 are protected H-Bridge drivers for automotive applications like headlight beam control and industrial servo control applications.
Integrated Low-Current Motor Drivers Motor Control ICs and industrial applications. The TLE4207 and TLE4208 parts are built using Infineon’s robust bipolar technology DOPL. TLE6208-3/-6 and TLE84xxx use SPT, a technology combining bipolar, CMOS and DMOS cells.
MOSFETs The TLE8203E is a derivative of the TLE8201R for automotive mirror control applications. The following output stages are included in this monolithic device, mirror position, mirror defrost and one lamp driver for 5 or 10W. TEMPFET ™ HITFET ™ The TLE8201R is an ASSP for door-module applications. It includes those power stages necessary to drive the following loads in a typical front door: Central lock, mirror fold, mirror position, mirror defrost plus 5 and 10W lamps.
Integrated High-Current Motor Drivers NovalithIC™/Trilith IC A NovalithIC™ provides a complete low-ohmic-protected half-bridge in a single package. It can be combined with an additional NovalithIC™ to create an H-Bridge or 3-phase bridge as well. The NovalithIC™ family has the capability to switch fast PWM signals while providing overcurrent, undervoltage and overtemperature protection. Current sense is available to monitor load current.
MOSFETs Low quiescent current Capable for high PWM frequency Protection Features Overvoltage Undervoltage Overtemperature Short-circuit/overcurrent PROFET ™ Diagnostic Features Overvoltage Overtemperature Short-circuit/overcurrent Current sense/status Open-load Smart Multichannel Switches Basic Features TEMPFET ™ HITFET ™ Trilith IC – Integrated H-Bridge Application Example Trilith IC i.e.
Integrated High-Current Motor Drivers NovalithIC™ – Integrated Half Bridge Basic Features Low quiescent current Capable for high PWM frequency Logic level input Adjustable slew rate Cross current protection Diagnostic Features Overtemperature Undervoltage Overcurrent Current sense and status Protection Features Overtemperature shutdown Undervoltage Overcurrent Application Example NovalithIC™ Microcontroller i.e.
future. Infineon’s family of configurable, H-Bridge and 3-phase gate driver ICs can be combined with MOSFETs to provide the power and efficiency these systems demand. C 3µF RVS 10Ω CVS 4.7µF INH ENA1 ENA2 VS CH1 CL1 CB1 VDH GH1 SPOC™ – SPI Power Controller SH1 GH2 SH2 CH2 GH3 CL2 CB2 Microcontroller or Digital ASIC 5V 5V LED Drivers U_fb V_fb W_fb ERR1 ERR2 IL1 IH1 IL2 IH2 IL3 IH3 DT SH3 GL1 SL1 TLE7183F GL2 SL2 GL3 SL3 VRI VRO Rfb ISP VTHOC RDT ADC GND VO Motor Drivers CCB2 4.
Gate Driver ICs for External MOSFETs Selection Tree Gate Drivers High-Current Motor Driver IC Solenoid & Valve Driver IC DC Brush Motor Each Output Stage with its own Input Pin 3 Phase Motor No OpAmp for Load Current Measurement PWM/DIR Interface 1 OpAmp for Load Current Measurement TLE7181 TLE7185E 3 OpAmps for Load Current Measurement System IC e.g.
MOSFETs Wiper Electric park brake Smart Multichannel Switches Diagnostic Features Basic Features PWM interface drives 1P and 1N Channel Power MOSFETs Separate control input for each MOSFET 0 … 100% Duty cycle of High and Low Side MOSFETs Adjustable dead time Fan and pump control One Error output to µC Over temperature protection Under voltage lock out Short circuit protection SPOC™ – SPI Power Controller Applications one low-side n-channel MOSFET.
Infineon® Embedded Power ICs System on a Chip Motor Control Infineon® embedded power ICs are specifically designed to enable mechatronic motor control solutions for a range of motor control applications, where a small package form factor and a minimum number of external components are essential. Examples applications include window lift, sunroof, wiper, fuel pump, HVAC fans, engine cooling fan, water pumps to name a few.
MOSFETs The TLE983x product family is offered in a space saving PG-VQFN-48 package, while the first product generation is realized as a Multi-Chip-Module (MCM) in a DSO-28 package. General Characteristics Operating voltage VBat: 3.
Infineon® Embedded Power ICs Product Name Core TLE983x Product Family TLE9835QX XC800 TLE9834QX XC800 TLE9833QX XC800 TLE9832-2QX XC800 TLE9832QX XC800 TLE9832QV XC800 Flash [KB] Freq [MHz] High-Side Switch High Voltage Monitor Input 16-bit Timer GPIO OP-AMP PN MOS Driver Package1) 64 64 48 36 36 36 40 40 40 40 40 40 2 2 2 2 1 1 5 5 5 5 5 5 5 5 5 5 5 5 11 11 11 11 11 11 Yes No No No No No Yes No No No No No 49 49 49 49 49 49 1) See packages on page 112 Smart LIN-based Relay
SPOC™ – SPI Power Controller PROFET ™ Smart Multichannel Switches TEMPFET ™ HITFET ™ MOSFETs General Characteristics Operating supply voltage Vs = 5.5 to 28V, maximum rating 40V Extended operating range Vs = 3.
Infineon® Embedded Power ICs Block Diagram LIN LIN Transceiver UART1 (LIN) Internal Supply 5V, 1.
MOSFETs TEMPFET ™ HITFET ™ PROFET ™ Motor Drivers LED Drivers SPOC™ – SPI Power Controller General Characteristics Operating supply voltage Vs = 5.5 to 28V, maximum rating 40V Extended operating range Vs = 3.
Infineon® Embedded Power ICs Block Diagram LIN LIN Transceiver UART1 (LIN) Internal Supply 5V, 1.
Glossary Automotive System ICs Automotive Transceivers Power Supply Motor Drivers LED Drivers SPOC™ – SPI Power Controller PROFET ™ Smart Multichannel Switches TEMPFET ™ HITFET ™ MOSFETs
Power Supply Linear Voltage Regulators Why do we need linear voltage regulators? In automotive ECUs, microcontrollers and other parts of the system have to be supplied by a stable and reliable voltage that is lower than the battery voltage (e.g. 3.3V or 5V) and works over the entire temperature range (from -40°C to 150°C). A linear voltage regulator converts a DC input voltage (e.g. battery line) into a pre-defined lower DC output voltage (e.g. 5V).
MOSFETs Actual Voltage Regulator Family Quiescent Current < 180µA Enable No Reset No TLE42664 TLE42764/76-2 TLE4286 TLE4296/-2 TLE7276-2 Watchdog TLE42644 TLE42744 TLE4294 TLE7274-2 TLF805113) Watchdog No 2) Early Warning TLE42344 TLE4284 TLE42901) TLE42364 No No TLE4263/-2 TLE4271-2 TLE42913) TLE4262 TLE4267 TLE4287 Early Warning No TLE42994G Watchdog Watchdog Early Warning TLE7272-2 No TLE4268 TLE4278 No TLE42994GM/E TLE4699 TLE7279-2 Reset No No TLE4678 TLE4678-23) TLE7273-2
Linear Voltage Regulators, Post Regulators, Voltage Trackers and DC/DC Converters High Performance Family Best in Performance Lowest dpm Rate dpm 0.1 Target 0dpm VOUT IOUT Excellent Line Transient Robustness 5–30µA 85°C Ultra Low Quiescent Current LV124 Severe Cranking 0 Defect Target & No Quality Events Design for Harsh Automotive Environment Suitable for Very Low Cranking (stop and start) + EN No Overshoot IOUT Output Voltage Soft Start 3.0V Extended Operating Range Starting at 3.
MOSFETs TEMPFET ™ HITFET ™ Ultra Low Drop Out 50mA 100mA 200mA 500mA Enable Reset No Reset No Reset No No TLS805B11) TLF805111) TLS810C11) Reset No TLS820B01) TLS850B01) SPOC – SPI Power Controller No PROFET ™ Enable Watchdog No TLS820F01) TLS850F01) LED Drivers 1) Available in 2015 Product Type TLF80511 NEW! IQ Iq [mA] [µA] 400 38 VS Range VQ [V] [V] 3.3–40 3.3; 5.
Linear Voltage Regulators, Post Regulators, Voltage Trackers and DC/DC Converters Linear Voltage Regulators by Output Current Product Type TLE4285 TLE4286 TLE4294 TLE4295 TLE4296 TLE4296-2 TLF4949 TLE42344 TLE42364 TLE4264-2 TLE42644 TLE4266-2 TLE42664 TLS202B1 TLS202A1 TLE42694 TLE42694-2 TLE42794 TLE42994 TLE4268 TLE7273-2 TLE7278-2 TLE7279-2 TLE4262 TLE4263/-2 TLE4278 TLE4678 TLE4699 TLF42774) TLE4287 TLE7270-2 TLE7272-2 TLE7274-2 TLE7276-2 TLS203B0 TLF4277-24) TLE4267-2 TLE42744 TLE42754 TLE42764 TLE467
MOSFETs TEMPFET ™ HITFET ™ l l 3) l l l l l l l l l l l l l l l l l l l l l l l l l l l l l l l l l l l l l l l l l l l l l l l l l l l l l l l l l l l l l 2) l l l l l l l l l l Smart Multichannel Switches 3) l 20 20 20 20 20 20 1 2 23 23 23 23 23 23 20 20 1 4 27 27 1 4 27 1 4 27 1 6 4 27 4 27 4 27 4 6 1 2 4 6 4 4 27 4 27 27 4 27 33 37 27 33 27 32 35 2
Linear Voltage Regulators, Post Regulators, Voltage Trackers and DC/DC Converters Tracker Family Output Current 50mA Yes No Yes TLE4250-2 Feedback Status 70mA 250mA 250mA 400mA Enable No TLE4254 Yes Feedback No Yes TLE4252 TLE4253 Enable No Yes No TLE4251 Block Diagram Trackers VBAT I VQ Voltage Regulator A Tracker requires an external voltage reference Load 1 ADJ Voltage Tracker External Load (e.g.
MOSFETs TEMPFET ™ HITFET ™ Post Regulator Family 500mA TLS203B0 Feedback No Yes Enable No Yes TLS205B0 No TLF1963 PROFET ™ TLS202A1 Yes Reset No Yes LS208D1 Advantages by Combining DC/DC & Linear Post Regulators Example Less power dissipation than linear regulator only PreRegulator based solutions Modular solution by using discrete ICs –– One simple-single-output DC/DC (ex: 3.3 to 10V) –– Other voltages generated by discrete post regulators (1.8V, 3.3V, etc.
Linear Voltage Regulators, Post Regulators, Voltage Trackers and DC/DC Converters Power Supply Multiple Output Regulators Product Type IQ 1 [mA] IQ 2/3 [mA] Iq [mA] VS Range [V] VQ 1 [V] VQ 2/3 [V] Drop Voltage [V] Accuracy [%] TLE4470 TLE4471 TLE4473/-2 TLE4476 TLE7469G 350 450 300 430 215 180 100/50 180 350 215 180 1,100 200 300 55 5.6–45 5.5–40(60) 5.6–42 5.7–42(60) 5.6–45 5 5 5 5 5 adj. 5.0 and 5.0 3.3 or 5.0 3.3 3.3 or 2.6 0.3 0.25 0.3 0.3 0.
MOSFETs TEMPFET ™ HITFET ™ 6/10 22/10/10 10/22 10/10 1/1 Overvoltage Protection l Reset Output Enable Adjustable Reset Threshold l l l l l l l l l Watchdog Early Warning Package1) l 4 6 8 3 33 3 l l l l l l l PROFET ™ l Smart Multichannel Switches Output Capacitance (min) [µF] [mA] adj. adj. adj. 350 105 and 50 105 and 50 105 and 50 6 x 17 [kHz] 1.5 0.120 0.120 0.120 7.0 0.045 0.045 0.045 0.045 0.
Automotive Transceivers Because of the ever-increasing demand for data exchange in modern vehicles, the automotive industry implemented networks like CAN (Controller Area Network), LIN (Local Interconnect Network) and FlexRay protocol-based bus systems. Infineon is offering a broad product portfolio of automotive transceivers for these different Automotive bus segments, that are perfectly suited and designed to withstand the harsh automotive environment.
MOSFETs TEMPFET ™ HITFET ™ Smart Multichannel Switches PROFET ™ SPOC™ – SPI Power Controller Selection Tree Automotive Transceivers High-Speed CAN (ISO 11898-2/-5) Fault Tolerant LS CAN (ISO 11898-3) TLE9221SX TLE9222PX1) Up to 20kbit/s LIN (LIN 1.3/2.1/2.2/2.2A; SAE-J2602) Motor Drivers FlexRay (EPL 3.0.
Automotive Transceivers Block Diagram Example High-Speed CAN: TLE7250GVIO 3 Transmitter CANH CANL 5 7 Output Stage 6 Driver 1 Timeout Temp.Protection 8 Mode Control Receiver VCC VIO TxD NEN VCC/2 = Comparator GND 4 * 2 RxD Block Diagram Example LIN: TLE7259-3GE VS 8 7 Supply 5V Mode Control 2 INH EN REN Output Stage RBus Bus 6 Driver TxD Input Temp.Protection Current Limit 4 Timeout Receiver TxD RTD 1 RxD Filter Wake and Bus Comparator WK 3 5 GND Filter www.
MOSFETs Iq [µA] Bus Wake-up Capability Wake-up Inputs Number of Channel Bus Failure Management Package1) High-speed CAN ISO 11898-2 TLE6250G 1Mbit/s TLE6250GV33 1Mbit/s TLE7250G 1Mbit/s TLE7250GVIO 1Mbit/s TLE8250G 1Mbit/s TLE8250GVIO 1Mbit/s < 10 @ 5V stand-by < 10 @ 5V stand-by < 10 @ 5V stand-by < 10 @ 5V stand-by < 10 @ 5V stand-by < 10 @ 5V stand-by 1 1 1 1 1 1 1 1 1 1 1 1 TEMPFET ™ HITFET ™ Transmission Rate (max) Smart Multichannel Switches Product Type
System Basis Chips (SBCs) The Driver SBCs Family The driver SBC is the first family of the new generation of Infineon SBC in an exposed pad PG-VQFN-48 (7mm x 7mm) power package. The family offers several variants to meet the different application requirements. The devices are designed for various CAN-LIN automotive body applications as a main supply for the microcontroller and as an interface for a CAN and LIN bus network (optional CAN partial networking).
MOSFETs Battery TEMPFET ™ HITFET ™ Application Diagram Fail Safe SYNC LIN Bus LIN CAN Bus HS-CAN CAN Protocol Handler High Precision Clock FO LDO1 LDO2 TLE9266(-2)QX TxD RxD LIN State Machine SPI SPI INT Wake Input WD RO Timer 1 PWM1 Timer 2 PWM2 PWM3 HS-SWT LS-SWT LS-SWT HS-SWT VS Hall Sensor PWM4 HS 3…6 VS RxD LDO1 LDO2 LS VCC1 VCC2 TxD RxD CAN GND Automotive System ICs HS 1…2 Output Drivers Automotive Transceivers WK 1…4 TxD Microcontroller XC2000 Glossary FO
System Basis Chips (SBCs) The Mid-Range SBCs Family Mid-Range SBC family offers a high level of integration, performance and scalability. Up to three low-drop voltage regulators with 5V or 3.3V output voltage, one HS CAN (including partial networking and flexible data-rate) and up to two LIN transceivers complying with the latest automotive standards and OEM requirements.
MOSFETs VBAT Battery TEMPFET ™ HITFET ™ Application Diagram Fail Safe HS SWT SPI Frame Compare Logic TxD, RxD State Machine INT 2 HV GPIO 3 Wake Input CAN Bus Microcontroller FO 3 FO CAN Protocol Handler Output Drivers 5V/3.3V LDO1 LIN Bus Power IC RO WD SPOC – SPI Power Controller Switches LDO2 LIN Bus LDO3 PNP Sensor Motor Drivers 5V/3.3V/1.
System Basis Chips (SBCs) Body System ICs – System Basis Chips Product Overview Product Type Family Name Transmission Rate (max) Iq [µA] IQ [µA] Vreg 1 [V] Vreg 2 [V] High-Speed CAN ISO 11898-5 / LIN 2.x and SAE J2602 TLE9266QX Driver SBC 1Mbit/s (CAN) 20kbit/s 10.4kbit/s (LIN) 25 (typ) Sleep Mode (Vreg 1 off) 53 (typ) Stop Mode (Vreg 1 on) 250mA @ 5V 100mA @ 5V TLE9266-2QX Driver SBC 1Mbit/s (CAN) 20kbit/s 10.
MOSFETs – 1x High-Speed CAN ISO 11898-5 1x LIN 2.x and SAE J2602 3 High-Voltage and 1 Low-Voltage Wake Inputs (cyclic sense) l 2x Low-Side Switch 250mA, 2x High-Side Switch 250mA, 4x High-Side Switch 150mA 49 – 1x High-Speed CAN ISO 11898-5 1x LIN 2.
Powertrain System ICs Constant Current Control ICs Features Four integrated low-side switches, control logic and outputs for external high-side switches Shorted load detection Open-load detection in ON-/OFF-State Short to ground detection Max. output average current approx. 1.
RDS(on) HS [mΩ] RDS(on) LS [mΩ] ILIM min. [A] IQ max. [mA] VS(OP) [V] Diagnostic IF TLE5205-2G TLE5206-2 TLE5206-2S TLE6209R TLE7209-2R TLE7209-3R TLE8209-2SA TLE8209-2E TLE8209-4SA TLE9201SG 220 220 220 140 150 150 115 115 115 100 220 220 220 130 150 150 125 125 125 100 6.0 6.0 6.0 3.4 … 5.95 5.5 5.5 1.0 … 7.7 1.0 … 7.7 1.0 … 9.0 5.0 10 10 10 0.05 20 20 0.02 0.02 0.02 0.03 6.0 … 40.0 6.0 … 40.0 6.0 … 40.0 5.2 … 40.0 5.0 … 28.0 5.0 … 28.0 4.5 … 28.0 4.5 … 28.0 4.5 … 28.0 5.0 … 28.
MOSFETs Smart Firing ICs and Power Supplies to Satellite Receiver ICs, Infineon is well positioned to meet the market’s requirements for cost efficiency, high quality and flexibility. Smart Multichannel Switches Infineon, a world leading supplier of Airbag ICs with more than 15 years experience, offers several complete solutions, enabling cost efficiency over the entire range from basic up to high end airbag systems.
Glossary 104 Type List Product Family Type List Product Family 2N7002DW Small Signal OptiMOS™ N-Channel 60V 25 BSP603S2L OptiMOS™ 55V (Planar) 15 BCR320U Linear LED Driver of BCR400 Series 57 BSP613P Small Signal SIPMOS™ P-Channel -60V 26 BCR321U Linear LED Driver of BCR400 Series 57 BSP742R Classic PROFET™ 46 BCR401U Linear LED Driver of BCR400 Series 57 BSP742RI Classic PROFET™ 46 BCR401W Linear LED Driver of BCR400 Series 57 BSP742T Classic PROFET™ 44 BCR402U Linear L
MOSFETs PROFET™+ 12V 50 BTN8982TA NovalithIC™ (Integrated High-Current Motor Drivers) 68 BTS5012-1EKB PROFET™+ 12V 50 BTS117TC HITFET™: Low-Side Protected Switches 33 BTS5012SDA High-Current PROFET™ 48 BTS118D HITFET™: Low-Side Protected Switches 33 BTS5014SDA High-Current PROFET™ 48 BTS133TC HITFET™: Low-Side Protected Switches 33 BTS5016-1EKB PROFET™+ 12V 50 BTS134D HITFET™: Low-Side Protected Switches 33 BTS5016-2EKA PROFET™+ 12V 50 BTS141TC HITFET™: Low-Side Protected Sw
Glossary 106 Type List Product Family Type List Product Family IPB120N06S4-H1 OptiMOS™-T2 60V (Trench) 19 IPB80N06S2L-H5 OptiMOS™ 55V (Planar) 14 IPB120N08S4-03 OptiMOS™-T2 80V (Trench) 20 IPB80N06S4-05 OptiMOS™-T2 60V (Trench) 19 IPB120N08S4-04 OptiMOS™-T2 80V (Trench) 20 IPB80N06S4-07 OptiMOS™-T2 60V (Trench) 19 IPB120N10S4-03 OptiMOS™-T2 100V (Trench) 20 IPB80N06S4L-05 OptiMOS™-T2 60V (Trench) 19 IPB120N10S4-05 OptiMOS™-T2 100V (Trench) 20 IPB80N06S4L-07 OptiMOS™-T2 60V
MOSFETs OptiMOS™-P2 40V P-Channel (Trench) 22 IPD80P03P4L-07 OptiMOS™-T2 30V P-Channel (Trench) 21 IPI22N03S4L-15 OptiMOS™-T2 30V (Trench) 17 IPD85P04P4-07 OptiMOS™-P2 40V P-Channel (Trench) 21 IPI45N04S4L-08 OptiMOS™-T2 40V (Trench) 18 IPD85P04P4L-06 OptiMOS™-P2 40V P-Channel (Trench) 21 IPI45N06S4-09 OptiMOS™-T2 60V (Trench) 19 IPD90N03S4L-02 OptiMOS™-T2 30V (Trench) 17 IPI45N06S4L-08 OptiMOS™-T2 60V (Trench) 19 IPD90N03S4L-03 OptiMOS™-T2 30V (Trench) 17 IPI45P03P4L-11 OptiMO
Glossary 108 Type List Product Family Type List Product Family IPP60R099CPA CoolMOS™ CPA 600 V 29 TLD1315EL Infineon® Basic LED Driver 59 IPP65R110CFDA CoolMOS™ CFDA 650 V 29 TLD1326EL Infineon® Basic LED Driver 59 IPP65R150CFDA CoolMOS™ CFDA 650 V 29 TLD2310EL Infineon® Basic LED Driver 59 IPP65R190CFDA CoolMOS™ CFDA 650 V 29 TLD2311EL Infineon® Basic LED Driver 59 IPP65R310CFDA CoolMOS™ CFDA 650 V 29 TLD2314EL Infineon® Basic LED Driver 59 IPP65R660CFDA CoolMOS™ CFDA 6
MOSFETs TLE7729 Satellite Receiver ICs 103 TLE6232GP Flex - Smart Multichannel Switch for Powertrain/Safety Applications 40 TLE7734 Airbag Firing ICs 103 TLE6240GP Flex - Smart Multichannel Switch for Powertrain/Safety Applications 40 TLE7738 Airbag Firing ICs 103 TLE6250G CAN Transceivers 93 TLE8102SG Flex - Smart Multichannel Switch for Powertrain/Safety Applications 40 TLE6250GV33 CAN Transceivers 93 TLE8104E Flex - Smart Multichannel Switch for Powertrain/Safety Applications 40
Infineon’s Next Level of Zero Defect Program On the Way to Zero Defect Products and Services The most valuable aspect of cars is the people they carry. Therefore, safety should never be compromised. This is the most important consideration for everybody involved in making automobiles – from the smallest suppliers to the manufacturers themselves. As car components become more and more complex, and as the number of control units in vehicles increases, the likelihood of a product failure becomes greater.
Packages1) 1 PG-DSO-8 2 PG-DSO-8 3 PG-DSO-12 4 PG-DSO-14 5 PG-DSO-14 6 PG-DSO-20 7 PG-DSO-20 8 PG-DSO-20 9 PG-DSO-24 10 PG-DSO-28 11 PG-DSO-36 12 PG-DSO-36 13 PG-DSO-36 14 PG-DSO-52 15 PG-HSOF-8-1 16 PG-LQFP-64 17 PG-MQFP-64 18 SC59 19 SC74 20 SCT595 21 SOT23 22 SOT89 23 SOT223 24 SOT323 25 SOT343 26 SOT363 27 PG-SSOP-14EP 28 PG-SSOP-16 29 PG-SSOP-24 30 PG-SSOP-24 31 PG-TDSON-8 dual 32 PG-TO252-3 33 PG-TO252-5
More detailed information on Automotive Power Products is available on our Web Site www.infineon.
Ask Infineon. Get connected with the answers. Infineon offers its toll-free 0800/4001 service hotline as one central number, available 24/7 in English, Mandarin and German. Our global connection service goes way beyond standard switchboard services by offering qualified support on the phone. Call us! Germany ................... 0800 951 951 951 (German/English) China, mainland ....... 4001 200 951 (Mandarin/English) India .......................... 000 800 4402 951 (English) USA ................
