www.aoc.com c 2010 AOC.All Rights Reserved.
Safety........................................................................................................................................................................ 4 National Conventions ......................................................................................................................................... 4 Power ................................................................................................................................................................
EPEAT Declaration .......................................................................................................................................... 59 Service ....................................................................................................................................................................60 Warranty Statement for Europe........................................................................................................................
Safety National Conventions The following subsections describe notational conventions used in this document. Notes, Cautions, and Warnings Throughout this guide, blocks of text may be accompanied by an icon and printed in bold type or in italic type. These blocks are notes, cautions, and warnings, and they are used as follows: NOTE: A NOTE indicates important information that helps you make better use of your computer system.
Power The monitor should be operated only from the type of power source indicated on the label. If you are not sure of the type of power supplied to your home, consult your dealer or local power company. The monitor is equipped with a three-pronged grounded plug, a plug with a third (grounding) pin. This plug will fit only into a grounded power outlet as a safety feature.
Installation Do not place the monitor on an unstable cart, stand, tripod, bracket, or table. If the monitor falls, it can injure a person and cause serious damage to this product. Use only a cart, stand, tripod, bracket, or table recommended by the manufacturer or sold with this product. Follow the manufacturer‟s instructions when installing the product and use mounting accessories recommended by the manufacturer. A product and cart combination should be moved with care.
Cleaning Clean the cabinet regularly with the cloth provided. You can use soft-detergent to wipe out the stain, instead of strong-detergent which will cauterize the product cabinet. When cleaning, make sure no detergent is leaked into the product. The cleaning cloth should not be too rough as it will scratch the screen surface. Please disconnect the power cord before cleaning the product.
Other If the product is emitting a strange smell, sound or smoke, disconnect the power plug IMMEDIATELY and contact a Service Center. Make sure that the ventilating openings are not blocked by a table or curtain. Do not engage the LCD monitor in severe vibration or high impact conditions during operation. Do not knock or drop the monitor during operation or transportation.
Setup Contents in Box Not all signal cables (Analog, Audio, DVI, and HDMI cables) will be provided for all countries and regions. Please check with the local dealer or AOC branch office for confirmation.
Setup Stand & Base Please setup or remove the base following the steps as below.
Adjusting Viewing Angle For optimal viewing it is recommended to look at the full face of the monitor, then adjust the monitor's angle to your own preference. Hold the stand so you will not topple the monitor when you change the monitor's angle. You are able to adjust the monitor's angle from -5° to 15°. NOTE: Do not touch the LCD screen when you change the angle. It may cause damage or break the LCD screen.
Connecting the Monitor Cable Connections On Back of Monitor and Computer: 1. DVI 2. Analog (DB-15 VGA cable) 3. Power To protect equipment, always turn off the PC and LCD monitor before connecting. 1 Connect the power cable to the AC port on the back of the monitor. 2 Connect one end of the 15-pin D-Sub cable to the back of the monitor and connect the other end to the computer's D-Sub port. 3.
Adjusting Setting Optimal Resolution Windows Vista For Windows Vista: 1 Click START. 2 Click CONTROL PANEL. 3 Click Appearance and Personalization.
5 Click Display Settings. 6 Set the resolution SLIDE-BAR to 1920 by 1080.
Windows XP For Windows XP: 1 Click START. 2 Click CONTROL PANEL. 3 Click Appearance and Themes. 4 Double click DISPLAY. 5 Click SETTINGS.
6 Set the resolution SLIDE-BAR to 1920 by 1080. Windows ME/2000 For Windows ME/2000: 1 Click START. 2 Click SETTINGS. 3 Click CONTROL PANEL. 4 Double click DISPLAY. 5 Click SETTINGS. 6 Set the resolution SLIDE-BAR to 1920 by 1080.
Hotkeys Source/Auto e-sensor/< 4:3 or>wide/> Menu/Enter Power 4:3 or wide image ratio hot key: When there is no OSD, press> continuously to change 4:3 or wide image ratio.(If the product screen size is 4:3 or input signal resolution is wide format, the hot key is disable to adjust) e-Sensor hot key. When there is no OSD,Press < continuously to select the e - Sensor mode (e-Sensor mode hot key may not be available in all mode ls).
OSD Setting Basic and simple instruction on the control keys. 1) Press the MENU-button to activate the OSD window. 2) Press ◄ or ► to navigate through the functions. Once the desired function is highlighted, press the MENU-button to activate sub-menu . Once the desired function is highlighted, press MENU-button to activate it. 3) Press ◄ or ► to change the settings of the selected function. Press ◄ or ► to select another function in sub-menu . Press AUTO to exit .
Luminance Press (Menu) to display menu. Press Menu to display MENU Press Menu to display MENU Press ◄ or ► to select (Luminance), and press to enter. Press ◄ or ►to select submenu, press to enter, and press ◄ or ► to adjust. Press 19 to exit.
Brightness 0-100 Backlight Adjustment Contrast 0-100 Contrast from Digital-register.
Image Setup Press (Menu) to display menu. Press ◄ or ► to select Setup), and press (Image to enter. Press ◄ or ► to select submenu, press to enter, and press ◄ or ► to adjust. Press 21 to exit.
Clock 0-100 Phase 0-100 H.Position 0-100 V.Position 0-100 Adjust picture Clock to reduce Vertical-Line noise. Adjust Picture Phase to reduce Horizontal-Line noise Adjust the horizontal position of the picture. Adjust the vertical position of the picture.
Color Temperature Press (Menu) to display menu. Press ◄ or ► to select (Color Temperature), and press to enter. Press ◄ or ► to select submenu, press to enter, and press ◄ or ► to adjust. Press 23 to exit.
Recall Warm Color Temperature Warm from EEPROM. Recall Normal Color Temperature Normal from EEPROM. Recall Cool Color Temperature Cool from EEPROM. Recall SRGB Color Temperature sRGB User from EEPROM. Red Red Gain from Digital-register Green Green Gain Digital-register.
Color Boost Press (Menu) to display menu. Press ◄ or ► to select Boost), and press (Color to enter. Press ◄ or ► to select submenu, press to enter, and press ◄ or ► to adjust. Press 25 to exit.
Full Enhance on or off Disable or Enable Full Enhance Mode Nature Skin on or off Disable or Enable Nature Skin Mode Green Field on or off Disable or Enable Green Field Mode Sky-blue on or off Disable or Enable Sky-blue Mode AutoDetect on or off Disable or Enable AutoDetect Mode Demo on or off Disable or Enable Demo 26
Picture Boost Press (Menu) to display MENU. Press ◄ or ► to select Boost); and press (Picture to enter. Press ◄ or ► to select Bright Frame. Select “on” to activate Picture Boost. Press ◄ or ► to select submenu, press to enter, and press ◄ or ► to adjust. Press 27 to exit.
Frame Size 14-100 Adjust Frame Size Brightness 0-100 Adjust Frame Brightness Contrast 0-100 Adjust Frame Contrast H. position 0-100 Adjust Frame horizontal Position V.
OSD Setup Press (Menu) to display menu. Press ◄ or ► to select Setup), and press (OSD to enter. Press ◄ or ► to select submenu, press to enter, and press ◄ or ► to adjust. Press 29 to exit.
OSD Setup Adjust the horizontal position of H.Position 0-100 V.
Extra Press (Menu) to display menu. Press ◄ or ► to select Setup), and press (OSD to enter. Press ◄ or ► to select submenu, press to enter, and press ◄ or ► to adjust. Press 31 to exit.
Input Select Select to Auto Detect input signal Auto Analog Digital Select Analog Sigal Source as Input Select Digital Sigal Source as Input Auto Config yes or no Auto adjust the picture to default Image Ratio wide or 4:3 Select wide or 4:3 format for display DDC-CI yes or no Turn ON/OFF DDC-CI Support Off Timer 0~24hours Select timing to turn off the monitor.
Reset Press (Menu) to display menu. Press ◄ or ► to select press (Reset), and to enter. Press◄ or ► to select YES or NO. Press 33 to exit.
Reset yes or no Reset the menu to default 34
Exit Press (Menu) to display menu. Press ◄ or ► to select press Exit to enter.
LED Indicator Status LED Color Full Power Mode Blue Active-off Mode Orange 36
Driver Monitor Driver Windows 7 1.Start Windows® 7 2.Click on the 'Start' button and then click on 'Control Panel'. 3. Click on the 'Display' icon.
4.Ckick on the “Change display settings” button. 5.Click the “Advanced Settings” button. 6.Click the “Monitor” tab and then click the “Properties” button.
7.Click the “Driver” tab. 8. Open the "Update Driver Software-Generic PnP Monitor" window by clicking on “Update Driver... “and then click the "Browse my computer for driver software" button. 9. Select "Let me pick from a list of device drivers on my computer".
10. Click the “Have Disk” button. Click on the “Browse” button and navigate to the following directory: X:\Driver\module name (where X is the drive letter designator for the CD-ROM drive). 11. Select the "xxx.inf" file and click the “Open” button. Click the “OK” button. 12. Select your monitor model and click the “Next” button. The files will be copied from the CD to your hard disk drive. 13. Close all open windows and remove the CD. 14. Restart the system.
Windows Vista 1. Click "Start " and "Control Panel". Then, double-click on "Appearance and Personalization". 2. Click "Personalization" and then "Display Settings". 3. Click "Advanced Settings...".
4. Click "Properties" in the "Monitor" tab. If the "Properties" button is deactivated, it means the configuration for your monitor is completed. The monitor can be used as is. If the message "Windows needs..." is displayed, as shown in the figure below, click "Continue". 5. Click "Update Driver..." in the "Driver" tab. 6. Check the "Browse my computer for driver software" checkbox and click "Let me pick from a list of device drivers on my computer". 7. Click on the 'Have disk...
Windows XP 1. Start Windows® XP 2. Click on the 'Start' button and then click on 'Control Panel'. 3. Select and click on the category „Appearance and Themes‟ 4. Click on the 'Display' Item.
5. Select the 'Settings' tab then click on the 'Advanced' button. 6. Select 'Monitor' tab - If the 'Properties' button is inactive, it means your monitor is properly configured. Please stop installation. - If the 'Properties' button is active, click on 'Properties' button. Please follow the steps below. 7. Click on the 'Driver' tab and then click on 'Update Driver...' button.
8. Select the 'Install from a list or specific location [advanced]' radio button and then click on the 'Next' button. 9. Select the 'Don't Search. I will choose the driver to install' radio button. Then click on the 'Next' button. 10. Click on the 'Have disk...' button, then click on the 'Browse...' button and then select the appropriate drive F: (CD-ROM Drive). 11. Click on the 'Open' button, then click the 'OK' button. 12. Select your monitor model and click on the 'Next' button.
Windows 2000 1. Start Windows® 2000 2. Click on the 'Start' button, point to 'Settings', and then click on 'Control Panel'. 3. Double click on the 'Display' Icon. 4. Select the 'Settings' tab then click on 'Advanced...'. 5. Select 'Monitor' - If the 'Properties' button is inactive, it means your monitor is properly configured. Please stop installation. - If the 'Properties' button is active. Click on 'Properties' button. Please follow the steps given below. 6.
i-Menu Welcome to “i-Menu” software by AOC. i-Menu makes it easy to adjust your monitor display setting by using on screen menus instead of the OSD button on the monitor. To complete installation, please follow the installation guide.
e-Sensor Welcome to AOC “e-Sensor” ! AOC “e-Sensor” is an infrared sensor embedded in your monitor bezel; it enables your monitor to turn off while you are away. To make it work, please use the designated hotkey to set up. Once you press the hotkey, you shall see the menu display below: The detectable range of the sensor is around 120cm, you may select near, average, or far to set the ideal range within which you would like the eSensor detect you.
e-Saver Welcome to use AOC e-Saver monitor power management software! The AOC e-Saver features Smart Shutdown functions for your monitors, allows your monitor to timely shutdown when PC unit is at any status (On, Off, Sleep or Screen Saver); the actual shutdown time depends on your preferences (see example below). Please click on "driver/e-Saver/setup.exe" to start installing the e-Saver software, follow the install wizard to complete software installation.
Screen+ Welcome to "Screen+" software by AOC, Screen+ software is a desktop screen splitting tool, it splits the desktop into different panes, each pane displays a different window. You only need to drag the window to a corresponding pane, when you want to access it. It supports multiple monitor display to make your task easier. Please follow the installation software to install it.
Troubleshoot Problem & Question Possible Solutions Make sure the power button is ON and the Power Cord is properly connected Power LED Is Not ON to a grounded power outlet and to the monitor. Is the power cord connected properly? Check the power cord connection and power supply. Is the cable connected correctly? (Connected using the D-sub cable) Check the DB-15 cable connection. (Connected using the DVI cable) Check the DVI cable connection. * DVI input is not available on every model.
The Computer Power Switch should be in the ON position. The Computer Video Card should be snugly fitted in its slot. Make sure the monitor's video cable is properly connected to the computer. Monitor Is Stuck In Active Inspect the monitor's video cable and make sure no pin is bent. Off-Mode" Make sure your computer is operational by hitting the CAPS LOCK key on the keyboard while observing the CAPS LOCK LED. The LED should either turn ON or OFF after hitting the CAPS LOCK key.
Specification General Specification Panel Resolution Product name i2340Ve Driving system TFT Color LCD Viewable Image Size 58.42 cm diagonal Pixel pitch 0.2652 mm(H) x 0.2652 mm(V) Video R, G, B Analog lnterface & Digital Interface Separate Sync. H/V TTL Display Color 16.7M Colors Dot Clock 148.5 MHz Horizontal scan range 30 kHz - 83 kHz Horizontal scan Size(Maximum) 509.184mm Vertical scan range 56 Hz - 75 Hz Vertical scan Size(Maximum) 286.
Operating 10% to 85% (non-condensing) Non-Operating 5% to 93% (non-condensing) Altitude: Operating 0~ 3658m (0~ 12000 ft ) Non-Operating 0~ 12192m (0~ 40000 ft ) Preset Display Modes STAND RESOLUTION Horizontal Vertical VGA 640×480@60Hz 31.469 59.94 640×480@72Hz 37.861 72.809 640×480@75Hz 37.5 75 800×600@56Hz 35.156 56.25 800×600@60Hz 37.879 60.317 800×600@72Hz 48.077 72.188 800×600@75Hz 46.875 75 1024×768@60Hz 48.363 60.004 1024×768@70Hz 56.476 70.
Pin Assignments Pin Number 15-Pin Side of the Signal Cable 1 Video-Red 2 Video-Green 3 Video-Blue 4 N.C. 5 Detect Cable 6 GND-R 7 GND-G 8 GND-B 9 +5V 10 Ground 11 N.C. 12 DDC-Serial data 13 H-sync 14 V-sync 15 DDC-Serial clock Pin No. Signal Name Pin No. Signal Name Pin No.
Plug and Play Plug & Play DDC2B Feature This monitor is equipped with VESA DDC2B capabilities according to the VESA DDC STANDARD. It allows the monitor to inform the host system of its identity and, depending on the level of DDC used, communicate additional information about its display capabilities. The DDC2B is a bi-directional data channel based on the I2C protocol. The host can request EDID information over the DDC2B channel.
Regulation FCC Notice FCC Class B Radio Frequency Interference Statement WARNING: (FOR FCC CERTIFIED MODELS) NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
WEEE Declaration Disposal of Waste Equipment by Users in Private Household in the European Union. This symbol on the product or on its packaging indicates that this product must not be disposed of with your other household waste.Instead, it is your responsibility to dispose of your waste equipment by handing it over to a designated collection point for the recycling of waste electrical and electronic equipment.
EPEAT Declaration EPEAT is a system to help purchasers in the public and private sectors evaluate, compare and select desktop computers, notebooks and monitors based on their environmental attributes. EPEAT also provides a clear and consistent set of performance criteria for the design of products, and provides an opportunity for manufacturers to secure market recognition for efforts to reduce the environmental impact of its products. AOC believes in protecting the environment.
Service Warranty Statement for Europe LIMITED THREE-YEAR WARRANTY* AOC Color Monitors sold within Europe AOC International (Europe) GmbH warrants this product to be free from defects in material and workmanship for a period of Three (3) years after the original date of consumer purchase. During this period, AOC International (Europe) GmbH will, at its option, either repair the defective product with new or rebuilt parts, or replace it with a new or rebuilt product at no charge except as *stated below.
modified or altered; you bear the sole responsibility and liability for any such modification or alteration. ALL EXPRESS AND IMPLIED WARRANTIES FOR THIS PRODUCT (INCLUDING THE WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE) ARE LIMITED IN DURATION TO A PERIOD OF THREE (3) YEARS FOR PARTS AND LABOR FROM THE ORIGINAL DATE OF CONSUMER PURCHASE. NO WARRANTIES (EITHER EXPRESSED OR IMPLIED) APPLY AFTER THIS PERIOD.
Warranty Statement for North & South America (excluding Brazil) WARRANTY STATEMENT for AOC Color Monitors Including those Sold within North America as Specified Envision Peripherals, Inc. warrants this product to be free from defects in material and workmanship for a period of three (3) years for parts & labor and one (1) year for CRT Tube or LCD Panel after the original date of consumer purchase. During this period, EPI ( EPI is the abbreviation of Envision Peripherals, Inc.
ALL EXPRESS AND IMPLIED WARRANTIES FOR THIS PRODUCT (INCLUDING THE WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE) ARE LIMITED IN DURATION TO A PERIOD OF THREE (3) YEARS FOR PARTS AND LABOR AND ONE (1) YEAR FOR CRT TUBE OR LCD PANEL FROM THE ORIGINAL DATE OF CONSUMER PURCHASE. NO WARRANTIES (EITHER EXPRESSED OR IMPLIED) APPLY AFTER THIS PERIOD.
